Automatic Insulating Glass Molecular Sieve Desiccant Filling Machine
Shandong Zunbo CNC Equipment Co., Ltd.- After-sales Service：Lifetime Maintenance
- Warranty：1 Year
- Condition：New
- Certification：ISO, CE
- Automatic Grade：Automatic
- CNC or Not：CNC
Base Info
- Model NO.：FZJ04
- Voltage：220V
- Numerical Control：CNC,Mnc
- Performance Classification：MID-Range CNC Machine Tools
- Application：Window
- Specification：1200x800x2900mm
- Trademark：Zunbo
- Origin：China
Description
Basic Info.
Model NO. FZJ04 Voltage 220V Numerical Control CNC/Mnc Performance Classification MID-Range CNC Machine Tools Application Window Specification 1200x800x2900mm Trademark Zunbo Origin ChinaProduct Description
Product Description:
Model: FZJ04PLC control system and touch screen interface.
Both bended and corner-connected spacers are available.
Adjustable filling height according to the spacer sizel.
Automatic sealing the drilled hole.
Automatic check-out system for molecular sieve filling.
Technical Parameter:
Power source: 220V 50HZ
Input Power: 1.0KW
Working air pressure: 0.6MPa
Molecular sieve diameter: 0.5-0.8mm
Filling speed: 5-8 seconds
Spacer width: 6-24mm
Dimension: 1200x800x2900mm
