• Model NO.：Model BB1135b
• Color：Customized
• Function：Woodworking Process
• Transport Package：as You Demand
• Trademark：JINGYUAN
• Origin：Linyi, Shandong, China
• HS Code：8465100000
• Production Capacity：100 Sets,Month

Company brandJINGYUANMInimum of quantity1x20GPDelivery timeWithin 15 days after got your depositShipping portQingdao and LianyungangCompany locationOur company is next to Linyi city bus station, Shandong province, China.

1 hour from Qingdao Liuting Internation Airport.
1.5 hours from Shanghai Pudong International Airport.
2.5 hours from Guangzhou Baiyun International Airport.Payment terms20% T/T in advance, 80% in the period of shipment or L/CContact informationMob: 0086-15806925262      Mr Willian
Product Details:
Basic Info
Model NO.: BB1135BType: Horizontal LatheTool Holder: Double-tool Holder CNC LatheAutomatic Grade: AutomaticPrecision: PrecisionSetting Mode: Floor-typeControlling Mode: CNCPower Source: ElectricProcessing Accessory: Chuck CNC LatheCertification: ISO
Technical specification:


Model	BB1135B
Permissible size of raw material	2600x1300x800mm
Cutter size	3500x200x20mm
Slice thickness	0.1-2mm(Different materials are different thickness)
Produce speed	5-32pcs/min
Clip block way	Hydraulic motor driven fixture coordinate with vacuum chuck
Total motor power	63.23kw
Main motor power	37kw(DC motor)
Hydraulic station motor power	5.5KW
The beam of the clamp motor power	4.3KW(servo motor)
Machine dimension	9300x5800x2820mm
Weight	29T


Product Description
Machine body:
1. Made of cast iron, the isothermal annealing treatment ensures the work stability and the vibration reducing performance.
2. Chromed columns, preventing wearing off
3. Well grind guide, guarantee the smoothness performance.
4. Roll feeding style, get small friction and ensure the life of conveyor belt.

Performance:
1. About 25 pcs of veneers per minute (based on 2 meter wood and cycle feeding system)
2. Cutting thickness shown in number, it can be as accurate as 0.01mm
3. Working table lifting controlled manually and automatically.
4. Equipped with wireless foot switch
5. Veneer output can be indicated by a counter
6. Automatic feeding speed can be adjusted by PLC
7. Veneer thickness can be from 0.5mm to 8mm according to wood harness
8. Veneer thickness error falls in ±0.05mm
