Vertex Software Light Gauge Steel Frame Stud Roll Forming Machine
Xiamen Xinhonghua Machinery Co., Ltd.- Warranty：1 Year
- Certification：CE, RoHS, GS, ISO9001
- Customized：Non-Customized
- Condition：New
- Control Type：Artificial
- Automatic Grade：Automatic
Base Info
- Model NO.：C89
- After-Sales Service Provided：Engineers Available to Service Machinery Overseas
- Control System：PLC(Imported Brand
- Roller Material：SKD-11
- Cutting Blade Material：SKD-11
- Shaft Material：40cr
- Un-Coiler：1.5t Hydraulic Steel Strip Un-Coiler with Automati
- Motor Power：5.5kw
- Hydraulic Motor Power：1.5kw
- Voltage：380V,50h,3pH
- Material Strip Thickness：0.6-1.2mm
- Transport Package：Paking
- Specification：3700*800*1100mm
- Trademark：XHH
- Origin：Fujian, China(Mianland)
- HS Code：84552290
- Production Capacity：20stes,Month
Description
Size
3700*800*1000mm
Weight
3T
Profile Size
89*38*9mm
Main Servo Motor Power
5.5KW
Hydraulic Motor Power
5.5KW
Voltage
380V/50HZ/3PH
Forming Steps
9+2steps for reshaping
Processing Speed
25-30m/min
Feeding Width
174mm
Efficient Width
89mm
Thickness
0.7-1.2mm
Tolerence Of Forming
±0.5mm
Color
Magic Green
Decoiler
5tons Decoiler
