• Model NO.：DX-120
• Transmission Method：Electric
• Effective：Easy Operation
• Motor Power：5.5kw
• Forming Station：13 Stations
• Medium Plate Thickness：14mm
• Main Frame：300h
• Diameter of Roller：75mm
• PLC：Delta Brand
• Type：Roll Forming Machine
• Method：Roll Forming Machine
• Transport Package：No
• Specification：CE, SGS
• Trademark：DIXIN
• Origin：Cangzhou City, Hebei Province, China
• HS Code：84552210
• Production Capacity：10sets,Per Month

Molding host

Model

Shibo-metal stud roll forming machine

Forming size

4500mm*1500mm*1300mm

weight

2.5 T

Host big frame structure

Frame welded

Roll station

14row

Axial material

45# steel

Out diameter of shaft

Φ50mm

Roller materials

CR12

Drive

By chain and gear

Sprocket chain

1 inch

Main power

7.5 kw

Working speed

45 m/min

Material thickness

0.3-1.0mm



Made board

25mm

2. Work flow
Manual decoiler- Roll forming machine- PLC control- Hydraulic system - Post cut- Stacking

3. Specific description
(1) Manual decoiler
Un-powered, single head, max capacity: 5000kg

(2) hydraulic pump station
It is controlled by gear wheel oil pump, after filling the hydraulic oil into the hydraulic oil tank, the pump drive the cutting machine to begin the cutting job.

(3) Computer control cabinet
It adopts TaiDa PLC to control, the target sheet length is adjustable.
Computed mode has two modes: Automatic and manual.
Touch screen.

(4) Output table
It is used to load the finished sheet. This kind is convenient for shipment.

(5) Spare parts

4. Payment term
TT, you should pay 30% as the deposit on the order day, then pay 70% before delivery when you inspect goods well in factory or by video

5. Warranty
24 months, and lifelong technical support service

6. Installation
If you need, we will send one technician to your factory to install & testing the machine. You should assist the technician to get Visa and pay for flight tickets and local accommodation, and pay 80 USD/day for salary.

7. Package
Standard export package, water-proof package, covered with plastic film

No.	Name	Unit	Qty
1	Manual decoiler	set	1
2	Main forming machine	set	1
3	PLC control system	set	1
4	Hydraulic pump station	set	1
5	Post cut and press	set	1
6	Electric motor	set	1
7	Output table	set	1

This is one of our main products, hotselling used in Nigeria, and has been certificated by SGS, CE.

Hope further contact with you.

If u have any other question,please contact me any time.
