• Model NO.：DXC80-300
• Condition：New
• Control Type：PLC
• Automatic Grade：Automatic
• Type：C,Z Shape Purlin Roll Forming Machine
• Power Source：Hydraulic Pressure
• Feature：High Efficiency
• Advantage：Use Widely
• Install：12 Months
• Pass：CCC, SGS, ISO9001, Ce
• Forging Forming Method：Mold Forging
• Material：Colored Steel Coil, Galvanized Coil, Aluminum Coil
• Produce Type：Roll Forming
• Product Name：C,Z Shape Purlin Roll Forming Machine
• Transport Package：Water-Proof Packaging, Covered with Plastic Film
• Specification：DX C80-300
• Trademark：DX
• Origin：Botou Hebei China
• HS Code：845522
• Production Capacity：20 Set Per Month

DIXIN hot sale C chanel building materials machineryModel NumberC purlin, 80-300Suitable Materialhot rolled strip steel, Q235 or equivalent, 1.5-3.0 mm thicknessMaterial Width175-465 mmDimensionabout 9.9*1.20*1.5  mWorking Spaceabout 19.9*3.2 mLength Of SheetYou can set the length according to your need, such as 1.5m, 3.2m or 6.7m. It is controlled by PLC, and can ensure the accuracy of ±2mm.CuttingAutomatically stop and cutting when it comes to the set lengthForming Speed0-15 m/minb. Components DetailsMaterialGr15.Main Frame400 H steel. More stable, no shakingMiddle Plate20 mm. we use bigger plates, to ensure stabilityChain2 inch thicknessShaft MaterialΦ80 mm, high grade 45# steel. Forming Steps13Detailed Forming Process3 steps for leveling- 12 steps for roll forming-5 steps for adjusting height and width-1 step on the coil-output part for adjusting deviation-1 leveling step to make it straight.Mold CuttingCr12, hardness HRC60-62. Treating process: heat treatment- plane abrasion- wire electrode cuttingControl SystemSuitable power: 380V, 50 Hz, 3 phase or according to your need.Screen: Delta 7 inch touch screen, easy to operatePLC: Delta DVP24ES, well-adapted to various conditions, such as moisture, electromagnetic disturbance.Frequency converter, Delta VFD-M. It has the advantage of slowing down before cutting, to ensure the length accuracyLength measurement device: Omron, made in Japan. It features with high accuracy and stabilityUsage



If you want to get more discount of C/Z Shape Purlin Roll Forming Machine export Kenya, please contact to me now!
Contact: Bella Hao    mobile: 008618231723279
