Building Material Making Machinery

Qt10-15 Fully Automatic Zig-Zag Brick Pressing Machine Pavement Block Plant

Linyi Raytone Machinery Imp&Exp Co., Ltd.
  • Certification:CE, ISO
  • Customized:Non-Customized
  • Automatic Grade:Automatic
  • Type:Concrete Iron Molding Machinery
  • Moulding Period:15-20s
  • Weight of The Host Machine:9.8t

Base Info

  • Model NO.:QT10-15
  • Workshop Area:260 M2
  • Host Machine Power:37kw
  • Vibration Force:100kn
  • Mixer Model:Js750
  • Voltage:380V,415V
  • Labour:10-12
  • Dimension:3500*2300*2930mm
  • Transport Package:Sea Transportation
  • Specification:3500*2300*2930mm
  • Trademark:Raytone Machinery
  • Origin:Linyi, China
  • HS Code:84748090
  • Production Capacity:50 Sets Per Month

Description

main technical parameters(1)Dimension of host machine3500*2300*2930mm(6)Host machine power37kw(2)Moulding period15-20s(7)Vibration force100KN(3)bamboo pallet size1300*900*30mm(8)Mixer modelJS750(4)Weight of the host machine9.8T(9)Voltage380V/415V(5)workshop area260 m2(10)labour10-12
4.QT10-15 brick Mahcine prodcuctivityproduction capacity Size(LxWxH)Pcs/Mould Pcs/ HrPcs/ 8 Hrpcs/month(1)400*250*20081200-14409600-11520288000-345600(2) 400*200*200101500-216012000-17280360000-518400(3)400*150*200142100-252016800-20160504000-604800(4)400*100*200203000-360024000-28800720000-864000(5)230*110*70427500-880060000-704001800000-2112000(6)200*100*60356300504001512000(7)200*163*6020360028800864000 Qt10-15 Fully Automatic Zig-Zag Brick Pressing Machine Pavement Block Plant

5.QT10-15 brick Machine area Needed:
Theoretical workshop requirements: 50 square meters, need 6-8 workers, one operates the mixer and feeds material, one operates the host machine, and two workers transport the blocks. The office, curing area, stacking area are arranged according to your specific conditions.
6.After-sale Service
We have our own technician team to do the machine installation for automatic brick machine line, and for some semi-automatic or manual block machine, normally user can operate the machine well, if technician is required, we can also meet the demand.
 And we provide 7*24 hours online service during after and before sales service.
7. Our Advantages
(1)Using the ultra strong steel and special welding techniques, it is strong and of high resistanceto vibration;
(2)Using imported electrical appliances, sealing parts and parts of hydraulic components, like Simens Motor, Simens PLC, Mitusbish PLC, or China famous brand motors, Switches, etc. the equipment's comprehensive performance is stable and reliable;
(3) our company focus on the technology of gearbox, which is key point of the brick machine, which can improve the productivity speed and block quantity.
8. FAQ
(1)Packing method ?
  Nude packing, or in plastic clothes, or in plywood box, accordingly.
(2)What's motor and electric brand we choose for our machine?
  Siemens brand, or Chinese famous brand.
(3) What kind of steel my machine and molds use ?
   Q235B for machine, Mn steel for molds. More durable.
(4) Will you send engineer to install for user?
   Yes, we have technician service team. They will supply service as per needs.
(5) Are there any spare parts together with the machine ?
  Yes, we will send spare parts together with machine, the user could use more than two years.
(6)Do you supply free technical service during later production ?
   Yes, we have online technical service in 24hours.
(7) What is the Warranty for the machine?
 For the machine,we have 1 years warranty(except the wearing part ).If any quality
problems on our side occured in this period ,we will take on the shipping cost and replacement.
Qt10-15 Fully Automatic Zig-Zag Brick Pressing Machine Pavement Block Plant
15.Company profile
Linyi Raytone Construction Machine Manufacture Co.,Ltd
(Export Division: Linyi Raytone Machinery Imp&Exp Co., L;td, was established in March of 2014), is located at Dazhuang Economic area, Yinan County, Linyi city, with 100 more staffwith a standard workshop of 22,000sqm, and owns comprehensive manufacture facilities and more than 200 sets of various finishing machines. We mainly manufacture all types of concrete block making machine, concrete batching plant and corollary equipment for the block machine line; The products have been sold widely to more than 60 countries. At present, we can manufacture 3,000 sets of construction machinery per year.
  Our company has set up a complete set of effective management system to strengthen the inner management, focusing on quality and after-sales services;
Sincere to the buyer, providing brilliant quality products, excellent service, competitive price and prompt delivery is our business principle;
Welcome worldwide friends to visit our company for further cooperation.

16.Crisa's Contact Details
Mob :+86 17861688115

PLEASE CONTACT US FOR FURTHER INFORMATION
