Qt10-15 Interlocking Block Moulding Plant Fully Automatic Block Forming Machine
Linyi Raytone Machinery Imp&Exp Co., Ltd.- Certification:CE, ISO
- Customized:Non-Customized
- Automatic Grade:Automatic
- Type:Concrete Iron Molding Machinery
- Moulding Period:15-20s
- Weight of The Host Machine:9.8t
Base Info
- Model NO.:QT10-15
- Workshop Area:260 M2
- Host Machine Power:37kw
- Vibration Force:100kn
- Mixer Model:Js750
- Voltage:380V,415V
- Labour:10-12
- Dimension:3500*2300*2930mm
- Transport Package:Sea Transportation
- Specification:3500*2300*2930mm
- Trademark:Raytone Machinery
- Origin:Linyi, China
- HS Code:84748090
- Production Capacity:50 Sets Per Month
Description
main technical parameters(1) Dimension of host machine 3500*2300*2930mm (6) Host machine power 37kw (2) Moulding period 15-20s (7) Vibration force 100KN (3) bamboo pallet size 1300*900*30mm (8) Mixer model JS750 (4) Weight of the host machine 9.8T (9) Voltage 380V/415V (5) workshop area 260 m2 (10) labour 10-12
4.QT10-15 brick Mahcine prodcuctivityproduction capacity Size(LxWxH) Pcs/Mould Pcs/ Hr Pcs/ 8 Hr pcs/month (1) 400*250*200 8 1200-1440 9600-11520 288000-345600 (2) 400*200*200 10 1500-2160 12000-17280 360000-518400 (3) 400*150*200 14 2100-2520 16800-20160 504000-604800 (4) 400*100*200 20 3000-3600 24000-28800 720000-864000 (5) 230*110*70 42 7500-8800 60000-70400 1800000-2112000 (6) 200*100*60 35 6300 50400 1512000 (7) 200*163*60 20 3600 28800 864000
5.QT10-15 brick Machine area Needed:
Theoretical workshop requirements: 50 square meters, need 6-8 workers, one operates the mixer and feeds material, one operates the host machine, and two workers transport the blocks. The office, curing area, stacking area are arranged according to your specific conditions.
6.After-sale Service
We have our own technician team to do the machine installation for automatic brick machine line, and for some semi-automatic or manual block machine, normally user can operate the machine well, if technician is required, we can also meet the demand.
And we provide 7*24 hours online service during after and before sales service.
7. Our Advantages
(1)Using the ultra strong steel and special welding techniques, it is strong and of high resistanceto vibration;
(2)Using imported electrical appliances, sealing parts and parts of hydraulic components, like Simens Motor, Simens PLC, Mitusbish PLC, or China famous brand motors, Switches, etc. the equipment's comprehensive performance is stable and reliable;
(3) our company focus on the technology of gearbox, which is key point of the brick machine, which can improve the productivity speed and block quantity.
8. FAQ
(1)Packing method ?
Nude packing, or in plastic clothes, or in plywood box, accordingly.
(2)What's motor and electric brand we choose for our machine?
Siemens brand, or Chinese famous brand.
(3) What kind of steel my machine and molds use ?
Q235B for machine, Mn steel for molds. More durable.
(4) Will you send engineer to install for user?
Yes, we have technician service team. They will supply service as per needs.
(5) Are there any spare parts together with the machine ?
Yes, we will send spare parts together with machine, the user could use more than two years.
(6)Do you supply free technical service during later production ?
Yes, we have online technical service in 24hours.
(7) What is the Warranty for the machine?
For the machine,we have 1 years warranty(except the wearing part ).If any quality
problems on our side occured in this period ,we will take on the shipping cost and replacement.
15.Company profile
Linyi Raytone Construction Machine Manufacture Co.,Ltd
(Export Division: Linyi Raytone Machinery Imp&Exp Co., L;td, was established in March of 2014), is located at Dazhuang Economic area, Yinan County, Linyi city, with 100 more staff, with a standard workshop of 22,000sqm, and owns comprehensive manufacture facilities and more than 200 sets of various finishing machines. We mainly manufacture all types of concrete block making machine, concrete batching plant and corollary equipment for the block machine line; The products have been sold widely to more than 60 countries. At present, we can manufacture 3,000 sets of construction machinery per year.
Our company has set up a complete set of effective management system to strengthen the inner management, focusing on quality and after-sales services;
Sincere to the buyer, providing brilliant quality products, excellent service, competitive price and prompt delivery is our business principle;
Welcome worldwide friends to visit our company for further cooperation.
16.Crisa's Contact Details
Mob :+86 17861688115
PLEASE CONTACT US FOR FURTHER INFORMATION
