Building Material Making Machinery

Home > Product > Tile Making Machine

750/980 Floor Decking Roll Forming Machine Product Line

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • After-sales Service：1
  • Warranty：1
  • Tile Type：Colored Steel
  • Certification：CE, Metal Deck Roll Forming Machine
  • Condition：New
  • Customized：Customized

Base Info

  • Model NO.：750,980
  • Usage：Roof, Wall, Floor, Metal Deck Roll Forming Machine
  • Transmission Method：Machinery
  • Product Name：Metal Deck Roll Forming Machine
  • Color：Blue
  • Control System：PLC Control System
  • Shaft：75mm
  • Thickness：0.3-1
  • Roller：High Grade 45# Steel
  • Main Frame：400h Steel
  • Hydraulic Pump Station：22kw
  • Chain：1 Inch
  • Voltage：380V or 220V
  • Transport Package：Nude, Covered with Plastic Film
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Botou, Hebei, China
  • HS Code：845522
  • Production Capacity：30 Sets,Month

Description

Main parameter for Metal Deck Roll Forming Machine1Suitable to processGalvanized/Aluminum/Color steel sheet2Width of plate1250mm3Thickness of plate0.3-0.8mm4RollersHigh grade 45# steel, with hard chrome plating5Forming steps166Sprocket chain1.5 inch7Pump station power22kw8Shaft75mm, high grade 45# steel, heat treatment9Hydraulic oil pumpCB-E31010WeightAbout 5.0 tons11Productivity8-12m/min12Cutting headCr12 mould steel with quenched treatment13Control systemTAIDA brand PLC control14Voltage380V 3Phase 60Hz15Motor power11kw16DimensionAbout 6.8m*1.5m*1.5m17Hydraulic pressure10-12mpa18Index error of length±1mm19The temperature range of working line-35-50°Above all the parameters can be changed exactly according to customer's requirements.
4. Advantage of DIXIN roll forming machineNo.DIXIN roll forming machine1High grade quality2Reasonable price3High efficiency4Low failure rate5Low energy consumption6Free after-sale service7Reliable working8Durable9Wide application10Beautiful appearance11Welcomed by all over the world customers12Professional foreign trade team13Mature technician team14Customize special type5. Want a free quotation for make budget?
Just send inquiry to me now!
6. We are your reliable partner!
We always do the best to make our machine perfect in every detail part.
Any pics or videos about machine, we can provide you.
7. Payment terms
30% T/T as the deposit when contract signed, 70% balanced before shipping.

our services


1.We can produce the specialmachine,send your drawing to us,we can desgin for you.

2. If you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.

3We provude a one year warranty and lifelong technical support,wa can send our technical to you to give you on-site training.The training period would be for no more than one week with the customer paying for the visa,return ticket,food ,accommodations and a daily wage of US100

4. Engineer available to service machinery overseas.

5. If you come to visit our factory ,we can book the room for you,car pick up to send.
750/980 Floor Decking Roll Forming Machine Product Line


8. Contact way
If you want to get more information about our equipment ,750/980 Floor Decking Roll Forming Machine Product Line
