• Information of Raw Material：748mm
• Thickness：2.5-3.5mm
• Yield Strength：Q235A Hr
• Main Power：22kw Two Sets
• Cutter Power：15.5kw(Pressure:25MPa) 3 PCS Cutter
• Speed of Machine：10-15meters,Min
• Structure：400I Beam
• Roll Stations：20 Roll Stations (with 6PCS Rollers for Leveling D
• Splint Thickness：22mm
• Diameter of Shaft：110mm
• Material of Shaft：Forged 45# Steel
• Type of Cutting：Hydraulic Cutting
• Transport Package：Water Proof Plastic Film Cover
• Trademark：ZHONGHENG
• Origin：China
• HS Code：8455221000
• Production Capacity：10 Sets ,Month

Item: Specification:Notes:1.Information of raw materialSuitable material:Galvanized coil Width:748mm Thickness:2.5-3.5mm Yield strength:Q235A HR 2.Production specificationDetailed as the file 3.Power requirement:Main power:22kw two setsWith inventor

(normal standard)Cutter power:15.5kw(pressure:25mpa)
3 pcs cutterSpeed of machine:10-15meters/min 4.Hydraulic de-coiler:Loading:5tonsMain power:3kwInner diameter508mmType:Automatic type5.Machine specification:Structure:400I beamTransform method : Gearbox with shaftRoll stations:20 roll stations
(with 6pcs rollers for leveling diameter:80mm) Splint thickness:22mmDiameter of shaft:110mm,Material of shaft:Forged 45# steelType of cutting:Saw cuttingMaterial of roller:CR12 with heat treatment:
HRC58-62Sizes of machine:15.5*1.0*1.5metersMaterial of punching mold:Cr12,hydraulic pre-punchingSizes of chain:2.0inch
