Steel/Galvaniced Steel/Aluminum Sheet Rectangular Drainage Pipe Roll Forming Machine

HEBEI XINNUO ROLL FORMING MACHINE CO., LTD.
  • Tile Type：Colored Steel
  • Certification：CE, ISO
  • Condition：New
  • Customized：Customized
  • Usage：Rectangular Drainage Pipe
  • Transmission Method：Hydraulic Pressure

Base Info

  • Model NO.：97*63
  • Roller Station：16 Rows
  • Productivity：10-15m,Min
  • Diameter of Shaft：66mm
  • Weight：About 4.0 T
  • Main Motor Power：5.5kw
  • Hydraulic Cutting Power：4 Kw
  • Voltage：380V 50Hz 3phase
  • Cutting Material：Cr12 Steel Treatment Hardn
  • Transport Package：Main Machine with Simple Film in The Container
  • Specification：8.0*1.35*1.4m
  • Trademark：KXD
  • Origin：China
  • HS Code：8455221000
  • Production Capacity：300 Sets,Year

Description

    Main parameters of Rectangular Drainage Pipe Roll Forming Machine 1Suitable to processColor steel plate, galvanized sheet,aluminum coils and etc.2 Size of Rectangular Drainage Pipe97*63mm or as customer request3Roller station16 rows4Feeding width of material330mm4Thickness of feeding material0.4-0.7mm5Productivity 10-15m/min6Rollers' material45# steel,Hot treatment hardness HRC55º-57º7Diameter of shaft66mm8Weight About 4.0 T9Size 8.0*1.35*1.4m10Voltage380V 50Hz 3Phase11Main motor power5.5kw12Hydraulic cutting power4 kw13Mould cutting materialCr12 steel
treatment hardness HRC60º-62º
2. Processing technique and deployment
Manual decoiler-Roll forming machine-PLC system-Hydraulic system-Post cut-Stacking
