Frame Door Steel Frame Steel Sheet Roll Forming Machine
HEBEI XINNUO ROLL FORMING MACHINE CO., LTD.- Tile Type：Colored Steel
- Certification：CE, ISO
- Condition：New
- Customized：Customized
- Usage：Door
- Transmission Method：Electric
Base Info
- Model NO.：frame door roll forming machine
- Transport Package：Naked
- Specification：KEXINDA
- Trademark：KEXIDNA
- Origin：China
- Production Capacity：2000 Sets,Year
Description
Main parameter of door frame roll forming machine1 Suitable to process Steel, galvanized sheet and etc 2 Width of the plate As customer need 3 Thickness of the plate As customer requirement 4 De-coiler Manual one, can load 5 tons raw material 5 Rollers for forming 16 rows 6 Diameter of the roller Φ70 mm 7 Rolling material Carbon Steel 45# 8 Main motor power 7.5kw 9 Productivity 8-15m/min 10 Cutting method Hydraulic mould cutting 11 Material of the cutting blade Cr12 12 Hydraulic cutting power 3kw 13 Processing precision Within 1.00mm 14 Control system Delta PLC control 15 Side panel of machine 14mm 16 Main structure of the machine 300 H steel 17 Weight About 3.6T 18 Dimensions 7.5*1.2*1.4m 19 Voltage 380V 50Hz 3phases(changeable as needs) 20 Certificate CE/ISO/TUV
