Roll Forming Machine for Yx63.5 Square Tube Profile

XIAMEN FUMING ROLL FORMING MACHINERY CO., LTD.
  • Tile Type：Gi, PPGI, Colored Steel
  • Certification：CE, SGS
  • Condition：New
  • Customized：Customized
  • Usage：Roof, Wall, Tube, Square Tube, Downpipe, Downspout
  • Transmission Method：Gear,Sprocket, Gear Box or Toroidal Worm Box

Base Info

  • Model NO.：YX63.5
  • Color：Customized
  • Transport Package：Container
  • Origin：Xiamen
  • HS Code：8455229090
  • Production Capacity：15 Sets,Month

Description

 ROLL FORMING MACHINE FOR YX63.5 SQUARE TUBE PROFILEDrawing               Material SpecificationThickness1.2mmMaterialGIFeeding widthApprox 283mmYield strength250MPa or customized Machine Components3Ton*600mm Hydraulic DecoilerCoil inner hole expandingHydraulic system, 2.2KW pump motorSpeed regulatingFrequency inverter, 1.5KW motorLoad capacityMax.3TonsCoil inner diameter510±30mmCoil outer diameterMax.1600mmCoil widthMax.600mm Pre-leveling DevicePre-Level Device with 4 over 3 shafts to remove the Coil-set, Manual control Roll Forming MachineDriving systemGear/sprocketForming station23 stationsRoller materialCr12, heat treatmentOption for roller materialCr12MovShaft diameterΦ75mmCooling systemAbove rollersMain motor18.5KW, frequency speed controlLine speed of rollformerApprox. 12-15m/min or customized Saw Cutting DeviceClampingPneumatically, air source provided by the buyerMotor for saw cutting7.5KWMotor for driving forward1.5KW PLC Control SystemFunctionControl quantity and and cutting length automaticallyPLCSiemensTouch screenSiemensInverterSchneider or DeltaEncoderOmronCut-to-length tolerance≤±2mm or customizedControl Voltage24V Product Rack6 meters×1
