• Model NO.：ZKX-2500x3100
• Voltage：380V
• System：PLC
• Automatic System：Fully Automatic
• Glass Process Max Size：2450*3150 mm
• Glass Process Min Size：300*500 mm
• Glass Process Thickness：3-12 mm
• Glass Washing Speed：0-12 mm
• Glass Transport Speed：45 M,Min
• Double Glazing Glass Thickness：10-48 mm
• Power Supply：3p 380V,1p +N220V 50Hz, Can Be Specially Order
• Total Power：38kw
• Space Size：22.8m *2.3m *3.55m
• Type：Vertical
• Programmable PLC：Omron
• Frequency Converter：Siemens
• Keyword：Insulating glass machines
• Transport Package：Plastic Film Packing
• Specification：2500*3100
• Trademark：LINGBO
• Origin：Shandong
• HS Code：8464901900
• Production Capacity：300 Lines,Year

ModelGlass process
Max size-mmGlass process
Max size-mmGlass process
Thickness -mmGlass washing
Speed-m/minGlass transport
Speed-m/minDouble Glazing
Glass thicknessPower supply
-KWSpace size
L*W*HYH-ZKX-
1800*24001800*24001800*24003-120-124510-48 mm3P 380V/1P
+N220V 50Hz, 26kw18m
*2m
*2.85mYH-ZKX-
2000*25002000*25002000*25003-120-124510-48 mm3P 380V/1P
+N220V 50Hz, 32kw19.5m
*2.2m
*3.05mYH-ZKX-
2000*30002000*30002000*30003-120-124510-48 mm3P 380V/1P
+N220V 50Hz, 38kw22.8m
*2.2m
*3.05mYH-ZKX-
2500*31002450*31502450*31503-120-124510-48 mm3P 380V/1P
+N220V 50Hz, 38kw22.8m
*2.3m
*3.55mYH-ZKX-
2500*40002450*39502450*39503-120-124510-48 mm3P 380V/1P
+N220V 50Hz, 42kw29m
*2.3m
*3.55mYH-ZKX-
2700*40002750*39502750*39503-120-124510-48 mm3P 380V/1P
+N220V 50Hz, 42kw29m
*2.7m
*3.70m
Notes: a. if you have special glass size, please note us, we can design the line for you;
b. If you have special power supply, please note us earlier as well, we can specially make the line for you.


3.Products Feature of High Speed Output IGU Glass Machine Insulating Glass Machines


WASHING MACHINE Washing Glass Thickness:  3-12mm Washing Speed: 0-12 m/min	ADVANTAGES: The whole washing section are made of stainless steel; Converter driving for Low-E brush rotatory speed; Automatically distinguish the coating side of coated glass and Low-E glass; Upper part of washing box use the bevel gear connects; Washing machine adopts oil less bearing.
SPACER ATTACHING SECTION	ADVANTAGES: Automatic detecting system for spacer frame; Automatic detecting system for glass; Hollowing out design, adopts the matte lights and The light tubes are controlled by two stages, saving energy; The aluminum spacer positioning adopts special design, accurate positioning, automatically inject the height and thickness of glass, saving labor; The backrest wheel adopts the inlaid design and the bearing is inside
OUTER ASSEMBLE SECTION	ADVANTAGES: Outer assembling glass, speed is fast; Adopts the Imported cylinder and photoelectric switch, make accurate positioning; can do three glass with two chambers; Special weight balancing system to make sure the workers and glass safety. Guideway, slide block, slide wheels adopts CNC processing.
PRESS MACHINE SECTION	ADVANTAGES: Adopts accurate positioning, make sure glasses press accurately; The plate of press machine adopts the CNC processing; The press open and close will adopts the air pump.
CONVERYOR SECTION	ADVANTAGES: Transmission wheel, the special design structure makes transmission wheel more durable; The conveyor section adopts the inlaid roller to facilitate the large glass delivery; The large frame uses 50mm × 100mm square standard steel tube, the equipment is more stable, enhance the stability of equipment operation. Can do three-sided glass (OPTIONAL).

4.Product Configuration Sheet


PROJECT NAME	BRAND	COUNTRY
Programmable PLC	OMRON	JAPAN
Frequency converter	SIEMENS	GERMANY
AC contactor	LS	KOREA
Low-E Glass Recognizer	OPTEX	JAPAN
Intermediate relay	HONEYWELL	USA
Breaker	LS	KOREA
Photoelectric switch	OPTEX	JAPAN
Proximity Switch	AUTONICS	KOREA
Pneumatic Solenoid valve	AIRTAC	TAIWAN
Pneumatic cylinder	AIRTAC	TAIWAN

5.FAQ

Q: Are you new to this High Speed Output IGU Glass Machine Insulating Glass Machines filed?
A: We are manufacturing these machines since 2014, and we have good name in home market, however we just start to open international market.

Q: What is your advantages compared the other supplier?
A: We supply high quality machines with high technology but with lower prices. Because our company goal is to Provide the most cost-effective products for the world.

Q: What is the service can you supply?
A: 1. Machine function introduction and quotation reply within 24 hours.
2.Industrial design or workshop layout design reply within 48 hours.
3.Customization feasibility reply within 72 hours.
4.Engineer onsite installation and operation guide if necessary.
5.Machine operation and maintenance guide service after sells.
6.Supply all the parts of the machine in whole lifetime.
7.PLC control system can be update and repaired in machine's whole lifetime!
8.Spare parts supplied in cost prices for all the clients.


6. Why choose us
A.Our company is the only high-tech enterprise in Shandong Province in the glass processing industry, enjoying a series of favorable policies such as national finance and taxation;

B.We have our own independent R&D team, especially employing field top Korean experts, having more than twenty patent certificates;

C.Large customer group give us full communication and feedback, making us get a wealth of industry knowledge and equipment installation experience, which is much better to serve next customers;

D.Having complete after-sales tracking and service team, able to serve our global customers well;

E.Complete protection system for regional distributors to well serve local end customers;

F.7X24 online supports

7. Machine Process of High Speed Output IGU Glass Machine Insulating Glass Machines
