Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine

Cangzhou Nexus Machinery Co., Ltd.
  • Warranty：1 Year
  • Certification：CE, ISO9001
  • Customized：Customized
  • Condition：New
  • Control Type：Electric
  • Automatic Grade：Automatic

Base Info

  • Product Name：Light Gauge Frame Wall Angle Roll Forming Machine
  • Coil Material Thickness：0.3-0.8mm
  • Processing Material：Galvanized Steel
  • Roller Material：Cr12MOV;
  • Rollers：10 Stands
  • Shaft Diameter：60mm
  • Cr-Plating Size：0.05mm
  • Cutter Standard：Cr12
  • Power：5.5+3kw
  • Roller Standard：45#Steel with Chrome Coating Heat Treatment
  • Transport Package：1.Control Box and Easy Damaged Parts:Protective PA
  • Specification：35-100
  • Trademark：Nexus Machinery
  • Origin：Cangzhou
  • HS Code：8455221000
  • Production Capacity：10

Description

ConfigurationsManual Uncoiler ,Guiding Platform ,Main Machine Of Roll Forming ,Electro-Motor,Cutting Device ,Hydraulic Station ,PLC Control, Supporter Table.Suitable to processColor steel plateWidth of the plate98/133/163mmControl SystemPLC Colored Touch ScreenRollers10 standsShaft Diameter60mmThickness of the plate0.3-0.8mmHydraulic Pressure10-12MPaRoller Standard45#steel with chrome coating heat treatmentCr-Plating Size0.05mmCutter StandardCr12Power5.5+3kwVoltage380V 50Hz 3phasesOverall Size2.3Tons
Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine

Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine
Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine
Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine



ABOUT US:

Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine

Automatic Bare Steel Light Gauge Frame Wall Angle Roll Forming Machine




FAQ:
1. How long the machine could be made?- Normally speaking, light gauge steel frame machine could
be made without 45 working days. If you need machines in a hurry, we can make it for you
less than a month.
2. How to visit your company?
-a.Fly to Beijing airport:   By high speed train From Beijing Nan to Cangzhou Xi (1 hour),
then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5
hours), then we can
pick up you.
3. Do you have after sales support?
-Yes, we are happy to give advice and we also have skilled technicians available across the
world.We need your machines running in order to keep your business running.
