• Model NO.：1500
• Vibrating Force：172 Kn
• Gross Weight：About 22t
• Transport Package：Standard Seaworthy Packing
• Specification：CE & ISO9001
• Trademark：QGM
• Origin：China
• HS Code：84748090
• Production Capacity：19280-23040

Production per mould

12pcs/mould (Hollow block: 390×190×190mm)

54pcs/mould (Solid block: 240×115×53mm)

27pcs/mould (Interlocking block: 225×112.5×60mm)

35pcs/mould (Holland brick: 200×100× 60-80mm)

Cycle time

15-25 seconds(Depending on product type)

Production per shift
(8 working hours)

Hollow block (390×190×190mm): 14400-19200pcs

Solid block (240×115×53mm): 77760-103680pcs

Interlocking block: 240×115×90mm): 31104-38880pcs

Holland brick (200×100×60-80mm): 40320-50400pcs.

Vibration frequency

2940 rolls/minute or 50-60 Hz

Vibrating force

120kN

Motors power

22kw

Volume of hoppers

Main material: 900L

Face material: 750L

Pallet size

1350×900mm

Gross weight

13.5 T (without face mix device)

17.5T (with face mix device)

Total power

67kw

Raw materials

Crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite and other industrial waste.

Applicable products

Concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, curbstones, grass blocks, slope blocks, interlocking blocks, etc.

Applied fields

Suitable for buildings, road paving, squares, gardens, landscaping, city constructions, etc.

Five advantages

1.Vibration System
Vibration table consists with dynamic table and static table. When vibration begin,dynamic table vibrate,static table remain static.The structure is designed to ensure the amplitude of the vibration table, so as to ensure the high quality of concrete products. Vibration table using HARDOX steel. Vibration mode: using the vibration table vibration + top mould vibration; vibration motor installation vibration damping device and air cooling device.

2.Feeding System
Motor use SEW motors, which control two mixing shafts. Feeding frame, bottom plate and mixing blade are made of high-duty HARDOX steel, the location of bottom plate can be adjusted.Feeding system have sealing device to prevent leakage. The door of the discharging gate is controlled by the SEW motor.

3.Hydraulic Station
Hydraulic pumps and hydraulic valves adopt international brands. Tube uses "Flange Connection", convenient installation and maintenance. Multi-point pressure detection point, convenient detection. Digital temperature and blockage alarm function. Motor and pump connection, flange connection, good coaxial. Dynamic proportional valve and constant power pump, speed regulation, voltage regulation, energy saving.

4.Germany Siemens PLC control system, Siemens touchscreen, Germany
Easy operation,low failure ratio, machine running stability and high reliability.Use the most-advanced industrial internet technology, realize remote trouble-shooting & maintenance. PLC and touchscreen use the PROFINET internet together, convenient for system diagnosis and WEB expansion. Achieve problem diagnosis and alarm system constantly, convenient for machine maintenance and troubleshooting. PLC running data for permanent preservation.

5.Frequency conversional technology & control
Reduce the motor starting current and soft start function control, prolong the life of the motor. Main vibration adopt low frequency standby, high frequency operation, improve the speed of operation and product quality. Reduce mechanical accessory and motor damage, prolong the life of the motor and mechanical.The frequency conveter saving about 20%-40% power than the traditional conveter.
