Kexinda Ridge Cap Cold Steel Roll Forming Machine Manufacturer
HEBEI XINNUO ROLL FORMING MACHINE CO., LTD.- Tile Type:Colored Steel
- Certification:CE, ISO
- Condition:New
- Customized:Customized
- Usage:Roof
- Transmission Method:Electric
Base Info
- Transport Package:Naked
- Specification:KEXINDA
- Trademark:KEXIDNA
- Origin:China
- Production Capacity:2000 Sets,Year
Description
Basic Info.
Transport Package Naked Specification KEXINDA Trademark KEXIDNA Origin China Production Capacity 2000 Sets/YearProduct Description
KEXINDA Ridge Cap Cold Steel Roll Forming Machine Manufacturer
• TECHNICAL PARAMETER:
Machine consist of uncoiler and its base, coil sheet guiding equipment, roll forming system, post cutting equipment, hydraulic station, controlling system, supporter table.
Material Spec: colored steel sheet; galvanized steel sheet
Thickness of coil sheet: 0.3-0.8mm
Main Motor Power:3 kw
Forming Speed: 10-12m/min
Hydraulic station power: 3kw
Quantity of stand:about 14
Hydraulic pressure:10-12mpa
controlling system: PLC
Index error of length:10m+2mm
Appearance sizes: 7.5x0.65x1 (L x W x H)
Total weight: about 3.5 tons
Voltage: 380V 3phase 60 HZ or at buyer's requirement
Material of main equipment
Roller material: high grade NO.45 forged steel, plated hard chrome on the surface of roller with thickness 0.05mm
Active shaft material: high grade NO.45 carbon wrought steel at Φ 65mm
Cutting blade: Cr12 mould steel with quenched treatment.
