• Model NO.：HNGK
• Name：Precision Stainless Steel Pipe Making Machine
• Thickness：1.0 - 8.0 mm
• Warranity：One Year
• Pipe Diameter：15 - 165 mm
• Speed：0.1 - 2.0 M,Min
• Transport Package：Container
• Specification：Φ 15 - Φ 165 mm
• Trademark：HNGK
• Origin：China
• HS Code：8515319900
• Production Capacity：5 Sets

Basic Info.

Model NO. HNGK Name Precision Stainless Steel Pipe Making Machine Thickness 1.0 - 8.0 mm Warranity One Year Pipe Diameter 15 - 165 mm Speed 0.1 - 2.0 M/Min Transport Package Container Specification Φ 15 - Φ 165 mm Trademark HNGK Origin China HS Code 8515319900 Production Capacity 5 Sets

Product Description

Precision Stainless Steel Pipe Making Machine

Precision stainless steel welded pipe mill adopts precise forming machine. It processes the steel sheet to the pipe. After welding, welding seam internal grinding, industrial black rust annealing, the industrial stainless welded pipe is produced. The welding seam of this pipe is very strong, no matter bending or flatten. It will not have the crack.
Precision stainless steel welded pipe mill is mainly used for manufacturing the industrial pipe in chemical, car, oil, and other fields. The pipe requirement on the material and quality is very strict. The machine has internal welding seam leveling treatment, solution annealing, X-ray detector, UT detector, high pressure hydrotester, and other detector equipments and art craft.

Model:

No.	Model	OD (mm)	Speed (m/min)	Thickness (mm)	Capacity(kw)	Area(M2)
1	HNBXG-32	Φ15~Φ32	0.1~2.0	1.0~2.5	~40	18×100
2	HNBXG-50	Φ21~Φ50	0.1~2.0	1.0~4.0	~45	18×100
3	HNBXG-60	Φ25~Φ60	0.1~2.0	1.5~4.5	~50	18×100
4	HNBXG-76	Φ32~Φ76	0.1~2.0	1.5~5.0	~55	18×120
5	HNBXG-89	Φ36~Φ89	0.1~2.0	2.0~6.0	~60	18×120
6	HNBXG-114	Φ50~Φ114	0.1~1.8	2.0~7.0	~70	18×120
7	HNBXG-127	Φ50~Φ127	0.1~1.8	2.0~7.0	~70	18×120
8	HNBXG-140	Φ60~Φ140	0.1~1.8	2.0~8.0	~75	18×120
9	HNBXG-165	Φ76~Φ165	0.1~1.8	2.0~8.0	~80	18×150

Process:

Uncoiler-Cutting and Welding-Small Accumulator-Forming-PPT Welding-Internal Welding Seam Leveling-Online Annealing-Water Cooling-Sizing-Cut to Length- Eddy Current Detector-Hydrotester-Solution Treatment-Acid Pickling Passivating-Weighting, Measuring, Marking-Pipe Collection

Services:

  1. Offer reasonable investment plan, reconmmend the appropriate models based on actual market situation.

  2. Offer layout of production line based on customer plant's drawings.

  3. Offer the base drawings required for installation.

  4. Offer machine's installation and commissioning by sending technicians, until machines operates normally.

  5. Offer professional training, until the buyer's operator command machine's operation.

  6. Offer and coordinate auxiliary components, accessories, and spare parts.

  7. The warranty is 1 year long, excluded situation of human-damage. If you have any question about machine operating, just contact us  via mails or phone call, we will solve the problem for you immediately.
