Building Material Prefabricated Light Steel House Keel Roll Forming Machines
Xiamen Xinhonghua Machinery Co., Ltd.- Warranty：1 Year
- Condition：New
- Certification：ISO, CE
- Automatic Grade：Automatic
- CNC or Not：PLC
- Voltage：380V
Base Info
- Model NO.：c89-5
- Coloror Uncoiler：Blue
- Roller Material：Gcr15
- Usage：Steel Structure of Building Projects
- Name：Light Steel Framing Machine
- Feature：Fully Automatic Operation
- Cutting Blade Material：Cr 12 High Grade Steel
- Application：House,Commercial Building
- Design Software：Vertex Bd
- Purlin Profile Combination：C+U or C+C
- Transport Package：Standard Packed for Export
- Specification：6tons
- Trademark：XHH
- Origin：China
- HS Code：8455229090
- Production Capacity：20sets,Month Light Steel Frames Forming Machine
Description
Size
3700*800*1100mm
Weight
2800KGS
Main Servo Motor Power
5.5KW
Hydraulic Motor Power
5.5KW
Forming Steps
10+2steps for reshaping
Processing Speed
Voltage
380V/50HZ/3PH
Lip of C Profile
10mm
Tolerence Of Forming
0.75mm
Forming Thickness
0.7-1.2mm
Height
38mm
2). Main Accessories:
(1).Main Purlin Forming Machine;
(2).5 Tons Hydraulic Uncoiler;
(3).Auto Guide Device;
(4).Hydraulic System;
(5).Design Software(Vertex Systems);
(6).Hydraulic Punching Device;
(7).Hydraulic Pre-cutting Device;
(8).Hydraulic Post-cutting Device;
(9).PLC Computer Controlling System with Touch Screen;
(10).Automatic Printing device;
(11).Run Out Table 4m;
(12).Tools;
(13).Operation Manual.
