• Model NO.：Various Model
• Output：100-1500tpd
• Experiences：50 Years
• Condition：New
• After Sale Service：for The Whole Using Life
• Spare Parts：We Offer
• Testing：We Offer
• Type：Cement Clinker Grinding Station
• Training：on Site
• Transport Package：Packing in Standard Containers or Meet Your Demand
• Specification：ISO9001, ISO14000, CE
• Trademark：zk
• Origin：Henan, China (Mainland)

No.

Item

Unit

Closed circuit production

1

Factory capacity

×10³t/a

100

160

250

350

500

2

Main material usage

Clinker

t/a

80000

128000

200000

280000

400000

Gypsum

t/a

5000

8000

12500

17500

25000

Pozzolana

t/a

15000

24000

37500

52500

75000

3

Energy consumption

Fresh water

t/a

4000

7000

9000

12000

17000

Electrical

kWh/a

3600000

5700000

8500000

1200000

1.7E+07

4

Layout transportation

Land area

15000

18000

20000

22000

24000

5

Project invest

Production line total invest

Ten

600

1000

1500

2000

2850

thousand

6

Workers

30

35

35

35

35

7

Main equipment

Ball mill

Φ2.2×6.5m

Φ2.4×11m

Φ3×11m

Φ3.2×13m

Φ3.5×13m

14t/h

24t/h

35t/h

50t/h

70t/h

380kW

630kW

1250kW

1600kW

2000kW

Belt conveyor

B500

B650

B650

B800

B1000

Mill outlet bucket elevator

TH315

TH400

NE100

NE150

NE200

Air classifier

NHX400

NHX600

NHX700

NHX800

NHX1000

(Osepa   N250)

(Osepa   N500)

(Osepa   N750)

(Osepa   N1000)

(Osepa   N1500)

Bag filter

PPC32-4

PPC32-6

PPC64-5

PPC64-6

PPC64-7

(PPC64-6)

(PPC96-7)

(PPC96-2×5)

(PPC96-2×6)

(PPC96-2×10)

Finished production bucket elevator

TH250

TH315

NE50

NE100

NE100

Screw conveyor

LS400

LS400

LS500

-

-

Packer

Three   nozzle

Four   nozzle

Six   nozzle

Eight       nozzle

Eight   nozzle

Belt weigher

B500×2000

B650×2500

B800×2500

B800×2500

B1000×3500

Cement grinding plant introduction:

cement grinding is the key equipment for secondary grinding after crushing. And it is suitable for grinding all kinds of ores and other materials, no matter wet grinding or dry grinding. Besides, it is mainly applied in many industries, such as ferrous&non-ferrous metal mine, building materials, chemical, electric power, coal, traffic, light industry, etc. In our company, this series of high-efficiency ball mill adopts rolling bearing support instead of sliding bearing support with bearing bush. Therefore, it can save energy by 10-20%. According to different discharging ways, it can be divided into two kinds, grate type and overflow type.

Cement Grinding's working principle:

The cement grinding  has horizontal cylindric rotating device, outer rotating with gear, two warehouses, is lattice-type ball mill. Material from the feeder device throuth hollow shaft of feeder evenly into the first warehouse of cement grinding , there are ladder liner and ripple liner in the warehouse , built by steel ball with different specifications , rotating cylinder produces centrifugal force take the ball to a certain height then fall,have a impact of the thumping and grinding for the material. After the material in the first warehouse reach coarse grinding,pass throuth single-wall partition into the second position, the warehouse lined with flat lining and steel balls in it ,have further grinding for the material . Powder discharged through the discharging plate to complete the grinding operation.

Cement grinding's structure:


This cement grinding is made up of feeder part ,discharging part ,rotating part ,transmission part(reducer,samll transmission gear ,motor,electric control) etc. main part.Hollow shaft adopt steel casting, lining can be converted,big rotating gear processed by casting gear hobbing .In the barrel there are board of wear-resistant,have a good characteriatics of wear-resisting.The machine is of steady operating and reliable working.


Host of ball mill include cylinder,and cylinder are equiped with liner made from wear-resistant material and bearing bear cylinder and maintain it to rotate ,also have driving parts,such as motor, and transmission gear, pulley, V-belt etc.

Company information:

Henan Zhengzhou Mining Machinery Co., Ltd is located in Wulong Industrial Park of Zhengzhou Xingyang which is the capital of Henan Province. It is at the junction of 310 State Road and Xingmi Road, close to the highway, railway station, West Zhongyuan Road, downtown area of Zhengzhou and Zhengzhou International Airport. The transportation condition is very convenient. The main products of company include: ball mill, rotary kiln, vertical preheater, cooler, crusher, metallurgical coke oven, magnetic separator, flotation machine, classifier, feeder, bucket elevator, preheater, dust collector, elevator, drier, and other equipments relate to metallurgy, cement, lime, mineral processing, refractory, chemical industry. The products of Henan Zhengzhou Mining Machinery Co., Ltd have been sold to every province of China and exported to Russia, Korea, Vietnam, Malaysia, Nepal, Bangladesh, Mexico, Armenia, Africa, South America and other countries and regions.



FAQ:


1. What's the biggest cement plant you can suppy?

     3000TPD

2. What's the technology you adopt for the cement plant?

     Dry Style with Preheater Technology

3. How many people needed to operate a cement plant?

     It's about 100-120 persons

Welcome to visit our company and workshop, we sincerely look forward to cooperating with  you. We will provide you with the most suitable products with the reasonable price.
