• Color of Machine：Blue or as Your Request
• Use：Roof
• Color：Blue
• Suitble Material：Galvanized Steel, Aluminum
• Forming Speed：13-15m,Min
• Hydraulic Station Power：5.5kw
• Controlling System：PLC
• Material Thickness：1.5-3mm or Customized as Your Request
• Application：Carriage Board
• Main Power of Motor：11kw
• Transport Package：According to Customers′ Request
• Specification：Jcx
• Trademark：JCX
• Origin：China Hebei
• HS Code：845221000
• Production Capacity：40sets Per Month

ITEMPARAMETERNOTE1.


 Suitable
material
 TypePre-painted sheet,
Galvanized sheet   Width(mm)450mm   Thickness(mm)0.4-0.5mm   Yield stress(mm)G220-G300 2.Product
specificationsDetail as the attached file  LengthAny length 3.Power
requirement
 Type220v/380v/3ph/50hzMotor brand shanghai Lichao  Main Motor power5.5kw   Cutter power4kw 4.Forming speed(m/min)10-15m/minNot include the time of cutting5.Manual Decoiler

(Optional)TypeManual   Max capacity5t   Suitable coil OD(MM)1000   Suitable coil
ID(MM)508 6.Forming stand13Depend on actual design7.Thickness of structure16mm 8.Forming shaft diameter(mm)70 solid 9.Type of cuttingRoll formed and length-set cutting 10.Control systemPanasonic PLC and inverter 11.Install dimension(depend on the final design)8.2m×1.5m×1mWithout panel length12.Total weight (Approx)5.5TDepend on final design

Introducation

1. This machine is made up of roll forming machine,molding press,cutting machine,PLC computer control and hydraulic system
2. The machine is stable,no noise,no shake
3. Controlling by computer, PLC display, operation is easy, running is steady and reliable,endurable, maintenance-free
4. cutting machine is characterized by stable driving, easy operation
5. hydraulic system use the CDF-10 hydraulic pump, long operating life,no noise
6. this machine is applies to roof fortification

Flow chart:

 Decoilling the sheet--sheet guilding--film covering--roll forming--measure length--cutting the panel--panel to the supporter



Machine Feature:

1.Precise forming

2. High-solid forming stand guarantees the goods and uniform high quality of final productd

3. The operation automatically minimizes the tolerance of cutting length

Products Feature:

1. A stylish and attractive design, giving the apperance of a traditional roof tile.

2. Resistant to frost, heat,hail and gales; 100% waterproof, due to the lateral run-off channel on each sheet for several models.

3.The raw material can be in different color, with elegant and noble looking. It is widely used as the garden like factory, hotel, exhibition, villa,civil construction etc.
