Steel Tile Metal Roof Roll Forming Machine/Sheet Rolling Machine

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • After-sales Service：1 Years
  • Warranty：1 Years
  • Tile Type：Colored Steel
  • Certification：CE, ISO, Shingle Metal Roof Tile Machine
  • Condition：New
  • Customized：Customized

Base Info

  • Model NO.：roof forming machine
  • Usage：Roof, Wall, Floor, Shingle Metal Roof Tile Machine
  • Transmission Method：Hydraulic Pressure
  • Product Name：Roof Forming Machine
  • Dimension(L*W*H)：6000mm*1500mm*1500mm
  • Tile：Colored Steel Roof
  • Place of Origin：Hebei, China (Mainland)
  • Feeding Width：1250mm
  • Material Thickness：0.25-0.8m
  • Type：Concrete Iron Molding Machinery
  • Method：Autoclaved Aerated Concrete
  • Processing：Brick Production Line
  • Product：Composite Material
  • Transport Package：Covered with Plastic Film
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Botou, Hebei, China
  • HS Code：845522
  • Production Capacity：30 Sets Per Year

Description

Molding hostweight5tonsHost big frame structureFrame weldedRoll station13rowAxial material45# steelOut diameter of shaftΦ75mmRoller materials45# steel hard chromium platingDriveBy chainSprocket chain 1 inchMain power:4kwWorking speed8-12 m/minMaterial thickness0.3-0.8mm Made board14mmHydraulic shearing
Material of bladeCr12,heat treatment 60-62°C
Shearing systemIt is controlled by gear wheel oil pump. After
filling the hydraulic oil into the hydraulic oil tank,
the pumps drive the cutter machine to begin the
cutting job.
The system includes a set of hydraulic tank, a
set of hydraulic oil pump, two hydraulic pipes.
And two sets of electromagnetism valves.
Power of the oil pump: 3kw
Hydraulic oil :40#

Electrical system
Main computer control cabinetIt adopts industrial computer to control. The target piece's
length is adjustable and digit of it can be adjusted. Computer
mode has two modes: automatic and manual one. The system
is easy to operate and use.
Processing precision : within 1.00mm
It contains liquid crystal screen, programmer, transformer
for the electronic machines and kits of every part.
Transducer brand is EURA.
The seller will provide Chinese and English language screen.

Factory show
Steel Tile Metal Roof Roll Forming Machine/Sheet Rolling Machine
Our excellent engineer
Steel Tile Metal Roof Roll Forming Machine/Sheet Rolling Machine

Welcome to contact me directly.
