• Model NO.：720 floor deck roll forming machine
• Usage：Roof, Wall, Floor Deck
• Transmission Method：Electric
• Color：as You Like
• Trade or Factory：Factory
• Guarantee：1 Year
• Life Time：10 Years
• Service：Provide Engineer to Install The Machines
• Brand Name of PLC：as Customer Request
• Drawing：Designed as Customer Request
• Power：38V, 50Hz, 3 Phrase or as Your Like
• Decoiler Type：Manul, Electric, Hydraulic
• Control System：PLC
• Transport Package：Main Machine Nude Packing with Plastic Film
• Specification：6800*1500*1500
• Trademark：KXD
• Origin：China
• HS Code：8455221000
• Production Capacity：30 Sets Per Month

Overview Product Description

1. the advantage of metal floor deck roll forming machine

Floor deck machine used for floor panel, it has high wave crest, high strength these features. And also automatic production, it has low cost good adhesiveness advantages. The product used in large workshop, roof construction and so on.
The whole equipment includes feeding platform, roll forming, automatic shearing device, hydraulic system, computer control system.
The suitable material can be color steel, aluminum sheet and galvanized sheet.
Configuration: manual unociler, main forming machine, gearbox motor, hydraulic system, cutter, output table.
Control system: automatically, adjustable speed, length-setting
2. Main Parameter and specification of the floor deck roll forming mchine
We design each machine according to user requirement. Below techinical parameters can be adjusted if needed.
 Technical parameters:1Name of commodity & specificationXN-688 Floor Deck roll forming machine2Main motor power18.5kw, 3 phase3Hydraulic motor power15kw4Hydraulic Pressure18-20MPa5Voltage380V /3phase/ 50 HZ (or as your requirement)6Control SystemPLC Delta Inverter7Main Frame450mm H-Beam8Backboard Thickness22mm9Chain Size66mm10Feeding Materialcolor steel coils11Feeding Thickness0.3-0.8mm12Feeding Width1000mm13Effective width688mm14Productivity8-10m/min15Roll Station2716Roller Diameter95mm17 Roller material 45# steel18 Cutter materialCr12 , quenched19Cr-Plating Size0.05mm20Overall Size15000×1200×1100mm21Total Weight19T22ComponentsManual Uncoiler-------------------1 set
Guiding Platform------------------1 set
Coil Strip Leveler------------------1 set
Main Machine of Roll Forming------1 set
Electric-Motor---------------------1 set
Cutting Device--------------------1 set
Hydraulic Station------------------1 set
PLC Control-----------------------1 set
Supporter Table-------------------1 set23WorkflowManual decoiling----feeding and guiding----roll forming----cut to length----run out table24Packagenude in the container25Minimum order quantity1 set26Payment termsT/T(30% T/T pay in advance, the remaining 70% pay before ship)27Delivery time30  working days later after receiving the depositAll technical parameters can be changed, according to user's need.Detailed Photos
