Metal Ridge Cap Tile Cold Roll Forming Machine

Botou Golden Integrity Roll Forming Machinery Co., Ltd.
  • Tile Type：Colored Steel
  • Certification：CE, ISO
  • Condition：New
  • Customized：Customized
  • Usage：Roof
  • Transmission Method：Machinery

Base Info

  • Model NO.：Ridge cap machine
  • Use：Roof
  • Color：Blue
  • Suitble Material：Galvanized Steel, Aluminum
  • Forming Stations：8
  • Motor：4kw
  • Hydraulic Motor：4kw
  • Speed：10m,Min
  • Roller Material：45# Steel with Heat Treatment
  • Shaft Material：70 Solid, 45# Steel with Heat Treatment
  • Chain：1.5 Inch
  • Transport Package：According to Customers′ Request
  • Specification：CE,SGS
  • Trademark：JCX
  • Origin：China Hebei
  • HS Code：84552210
  • Production Capacity：40sets Per Month

Description

main parameter of ridge tile roll forming machine1Suitable to processColor steel sheet2Width of the plate320mm3Roller steps14 rows4Dimensions6.8m*0.9m*1.51m
(depend on different profile)5Power3+3kw(according customer's requirement)6Thickness of the plate0.3-0.8mm7Productivity1-3m/min8Diameter of the shaftΦ60mm9WeightAbout 5.5T10Voltage380V 50Hz 3 phases11Material of the cutting plateCr1212Hydraulic40#13Processing precisionWithin 1.00mm14Control systemPLC control15Diameter of roller70mm16Hydraulic oil40#
