Building Material Making Machinery

Rolling Shutter Door Slats Roll Forming Machine

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Certification:CE, RoHS, GS, ISO9001
  • Customized:Customized
  • Condition:New
  • Control Type:CNC
  • Automatic Grade:Automatic
  • Drive:Hydraulic

Base Info

  • Model NO.:DX-75
  • Name:Rolling Shutter Slats Roll Forming Machine
  • Material Specification:Aluminum, Galvalume, Galvanized and Pre-Painted Ga
  • Thickness:0.5 mm to 1.5mm
  • Main Motor Power:4 Kw
  • Hydraulic Station Power:3 Kw
  • Feeding Width:Depends on The Model of Profile
  • Yield Stress:235MPa(33ksi) ~ 345MPa (50ksi)
  • Roll Forming Speed:12 M,Minute.
  • Cutting Tolerance:+,-2.5mm(Length≤5000mm)
  • Numbers of Stands:12 Stands,Stations,Pairs for Each Roll Forming Sys
  • Transport Package:Simple Waterproof Fit for Ocean Ship, Need a 20 Gp
  • Specification:CE ISO BV
  • Trademark:DIXIN
  • Origin:Botou City, Hebei Province
  • HS Code:84552210
  • Production Capacity:20 Set Per Year

Description


Material specification
Aluminum, galvalume, galvanized and pre-painted galvanized steel.
Thickness
0.5 mm to 1.5mm.
Main motor power
4 kw.
Hydraulic station power
3 kw.
Feeding width
Depends on the model of profile.
Yield stress
235Mpa(33KSI) ~ 345Mpa (50KSI).
Roll forming Speed
12 m/minute.
Cutting Tolerance
+/-2.5mm(length≤5000mm); +/-3.0mm(5000mm<length≤10000mm).
Manual Uncoiler
Max. Capacity: 3000kgs.
Coil inner diameter
508mm.
Voltage
As per customer's request.
Numbers of stands
12 stands/stations/pairs for each roll forming system.
Type of cutting
Roll-formed and length-set profile cutting.


Advantage of shutter roll forming machine:
1. Variable frequency speed control
2. Latest type, little noise
3. High precision in forming and cutting
4. High efficiency
5. Widely use


Our Services
Why Choose us/Simple advantage in words

1Direct Factory in China Since 20082Good design and professional engineers more than 20 years experience3CE SGS BV AS--- authentication available4Overseas service available/one year quality guarantee5Good credit6Many other designs available and special design available
Our Service
1. we can produce the special machine,send your drawing to us,we can design for you.
2. if you buy our products,we also can help you to purchase the material,like color roll,the price is lower than you buy by yourself.
3. we provide a one year warranty and lifelong technical support, we can send our technicians to you to give you on-site training.
The training period would be for no more than one week with the customer paying for the visa, return ticket, food, accommodations and a daily wage of US80.
4. engineers available to service machinery overseas.
5. if you come to visit our factory,we can book the room for you, car pick up to send.


Company Information
Company Introduce:
Our enterprise, Cangzhou Dixin Roll Forming Machine Co., Ltd, as the professional and leading manufacturer, can manufacture, design, installation and debug various roll forming machines and metal processing sheet equipments, which produce metal roof wall panel, glazed roof tile, CZ steel  purlin, floor decking, roof ridge cap, sandwich panel, roof truss, shutter panel, shutter slat, door frame, guardrail, and metal sheet uncoiler, bending, slitting, cutting, flattening, punching, crimping.
Backed by reasonable design, precision machining and selected material, both our standard and customized machines are characterized by long life span, precise forming and easy operation. With our customers' trust, our machines have been sent to America, Australia, Russia, India, Sri Lanka, Nigeria, Pakistan, Uzbekistan, Mozambique, Angola, Turkey, Brazil, etc.
Warmly welcome to China to visit our factory and select the machines you need. Our address,Fuzhuang Industrial Development Zone, Botou City, Hebei Province, China

If u have any interest,please contact me any time
