Factory Price Colored Steel Double Layer Roofing Sheet Metal Plate Two Types Trapezoidal Roof Panel Roll Forming Machine for PPGI
Hangzhou Zhongyuan Machinery Factory- Tile Type:Glazed Steel
- Certification:CE, ISO
- Condition:New
- Customized:Customized
- Usage:Roof, Wall
- Transmission Method:Electric
Base Info
- Model NO.:Double Layer Roll Forming Machine
- Name:Double Layer Roll Forming Machine
- Material of Cutter:Cr12 Mould Steel with Quench Treatment, HRC58-60
- Material of Forming Rollers:No.45 Steel, Plated with Chrome on Surface.
- Certificate:ISO,Ce,Soncap
- Transport Package:1*40FT Container
- Specification:CE SGS BV
- Trademark:Zhongyuan
- Origin:China
- HS Code:84552210
- Production Capacity:10sets,Month
Description
ItemSpecification
Material Type Pre-painted steel coil & galvanized coils Thickness(mm) 0.4-0.7 Yield strength(mpa) 235-345 Roller material 45#Chrome steel Forming speed(m/min) About 20-25 Speed adjusting mode AC Frequency Roller drive Decelerating motor + Chain drive Cutting mode Hydraulic cutting Cutter material Cr12 mould steel Length measurement Encoder Control mode Mitsubishi PLC Operating mode Button + Mitsubishi Touch screen Main motor power(kw) 7.5 KW Total power(kw) 9.7 KW
Components of machine Decoiler 1set Feeding & guiding device 1set Main roll forming machine 1set Hydraulic cutting system 1set Controlling system 1set Output Table 1set
Process flowDecoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - Output Table
About us
1. CE, ISO certificate by SGS.
2. Mitsubishi PLC controller and transducer from Japan
3.12moths warranty, lifetime technical support
4. Capacity: 12 sets/month
5. Delivery: In only 5-8 weeks for urgent order
6. Company occupies 6650, in which 5650 for workshops
7. Have our own tool center. 12 sets CNC machines.
8. Rollers covered with 0.05mm hard chrome.
9. Customize machines, R&D team with 15 years well-experience in design machine
10. Third party inspection: Bureau Veritas, SGS. Can provide assessment report.
11. Machine original brand: Zhongyuan
12. Set up business relationship with companies in more than 20 countries
