C89 Profile Drywall Roll Form Machine C 89 Drywall Stud and Track Roll Forming Machine Stud
Cangzhou Dixin Roll Forming Machine Co., Ltd.- Tile Type：Pi
- Certification：CE, ISO
- Condition：New
- Customized：Customized
- Usage：Roof, Wall, Floor
- Transmission Method：Electric
Base Info
- Model NO.：stud and track roll forming machine
- Material：Colored Steel Sheet, Galvanized Steel Sheet, Alumi
- Thickness of Coil Sheet：0.3-0.8mm
- Efficiency Width：25,30mm
- Roller Material：High Grade No. 45 Forged Steel
- Shaft Material：High Grade No. 45 Carbon Wrought Steel
- Cutting Blade：Cr12 Mould Steel with Quenched Treatment
- Diameter of Shaft：70mm or as Your Requirement
- Main Frame：300 H Steel
- Forming Steps：16 Stations
- Productivity：30-35m,Min
- Hydraulic Station Power：5.5 Kw
- Hydraulic Pressure：10-12MPa
- Appearance Size：7700mm*1500mm*1500mm
- Hydraulic Oil：40# Hydraulic Oil
- Electric Tension：380V 50 Hz 3 Phase or as Your Requirement
- Transport Package：Nude
- Specification：5500*800*1200mm
- Trademark：DIXIN
- Origin：Botou, Hebei, China
- HS Code：84552210
- Production Capacity：100 Set,Year
Description
Material
Colored steel sheet, galvanized steel sheet, aluminum sheet
Thickness of coil sheet
1.0-2.0mm
Efficiency width
25/30mm
Machine details
Roller material
High grade NO. 45 forged steel with 0.05mm hard chrome plating
Shaft material
High grade NO. 45 carbon wrought steel
Cutting blade
Cr12 mould steel with quenched treatment
Diameter of shaft
70mm or as your requirement
Main frame
300 H steel
Forming steps
16 stations
Productivity
30-35m/min
Hydraulic station power
5.5 KW
Hydraulic pressure
10-12MPa
Appearance size
7700mm*1500mm*1500mm
Hydraulic oil
40# hydraulic oil
Electric tension
380V 50 Hz 3 Phase or as your requirement
Cut Mode
Hydraulic forming after cutting off
Cutter materia
Cr12 Heat Treatment
Electronic control system
PLC, Touch Screen, Encoding counter
Color
Blue, green or yellow or as your requirement
Rolling material
45# steel,roller surfaces polishing, hard plating
1. Installation and training:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary
things.
2. After Service
a.One year guarantee for whole machine.
b.24 hours technical support by email or calling
c.If there is any problem found of the machine, we will repair it for free in one year.
