38-150mm Interlocked Flexible Metal Hose Machine, Flex Exhaust Pipe Machine^

Comflex Industrial Co., Ltd.
  • After-sales Service：Online Video Guidence
  • Warranty：One Year
  • Pipe Material：Stainless Steel
  • Condition：New
  • Customized：Customized
  • Theory：Inverter

Base Info

  • Model NO.：HLT
  • Application：Exhaust System
  • Type：Pipe Production Line
  • Material Grade：Stainless Steel 304,316,316L,321,Galvanized Steel
  • Pressure：-10 to 100 Bar
  • Temperature：-40 Degree to 120 Degree
  • Voltage：380V
  • Oveaseas Installation：Available
  • Weight：1000kg
  • Power：11kw
  • Pipe Type：Interlock
  • Product Name：Interlocked Flexible Metal Hose Machine
  • Transport Package：Standard Seaworthy & Strong Package
  • Specification：ISO9001
  • Trademark：Comflex
  • Origin：China
  • HS Code：84748020
  • Production Capacity：500 Sets,Year

Description

Technical data for interlock hose making machineSize rangeID6-ID26mmID30-50mmID38-150mmID75-300mmID200-400mmID38-65mmProduction speed50-180m/hr50-180m/hr100-120m/8hr150-400m/8hr100-120m/8hr150-400/8hrStrip size7-9*0.18-0.23mm7-9*0.18-0.23mm16,20mm*0.25-0.5mm20*0.45mm28*0.5-0.8mm15*0.25mmProduction typeroundroundRound/polygonalRoundroundpolygonal

38-150mm Interlocked Flexible Metal Hose Machine, Flex Exhaust Pipe Machine^

 Interlock Flexible Hose Making Machine Available shapeRound/PolygonSize rangeID150-600Forming spped100-200m/8hrsStrip thickness0.25-0.8mmStrip width16, 20, 28, 32mmPower11KWOuter dimension3500*1200*1600mm
38-150mm Interlocked Flexible Metal Hose Machine, Flex Exhaust Pipe Machine^
 Welcome to inquiry us!
