• Model NO.：DX
• Color：Blue,Red, Yellow
• Machine Name：Steel Profile Making Machine
• Material Thickness：0.3-0.8mm
• Electric Motor：5.5kw
• Max Width：100mm
• Voltage：380V
• Weight：2.8 Tons
• Roller：High Grade 45# Steel, with Hard Chrome Plating
• Shaft：75mm
• Control System：PLC
• Transport Package：Nude, Covered with Plastic Film
• Specification：CE SGS ISO
• Trademark：DIXIN
• Origin：Botou, Hebei, China
• HS Code：84552210
• Production Capacity：40 Sets Per Month

Molding hostModel DX--roof tile forming machineForming size6000mm*1200mm*1000mmweight3 tonsHost big frame structureFrame weldedRoll station13rowAxial material45# steelOut diameter of shaftΦ75mmRoller materials45# steel hard chromium platingDriveBy chainSprocket chain 1 inchMain power:4kwWorking speed8-12 m/minMaterial thickness0.3-0.8mm
 Made board14mm
3. Hydraulic shearingMaterial of bladeCr12,heat treatment 60-62°CShearing systemIt is controlled by gear wheel oil pump. After
filling the hydraulic oil into the hydraulic oil tank,
the pumps drive the cutter machine to begin the
cutting job.
The system includes a set of hydraulic tank, a
set of hydraulic oil pump, two hydraulic pipes.
And two sets of electromagnetism valves.
Power of the oil pump: 3kw
Hydraulic oil :40#
4. Electrical systemMain computer control cabinetIt adopts industrial computer to control. The target piece's
length is adjustable and digit of it can be adjusted. Computer
mode has two modes: automatic and manual one. The system
is easy to operate and use.
Processing precision : within 1.00mm
It contains liquid crystal screen, programmer, transformer
for the electronic machines and kits of every part.
Transducer brand is EURA.
The seller will provide Chinese and English language screen.






Equipment Use:Equipment of plate type is suitable for large factory,temporary housing,Outdoor steel structure roof panel,beautiful,Suitable for outdoor building,The plate for the lap type structure.

After-sales service and installation:Our factory with perfect after-sales service,And can according to user requirements design and manufacture of the special type,To the user guide at the same time, production, installation, debugging, maintenance.

Machine Features: Our sales of such type of tile press, by domestic and foreign customers consistent high praise, The equipment of exquisite workmanship, plate type standard, its biggest characteristic is suitable for site use, Good anticorrosive property, is the first choice for customers



If u have any other question, please contact me any time
