Light Steel Keel Metal Furring Keel Channel House Structure Roll Forming Machine

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Certification：CE, RoHS, GS, ISO9001
  • Customized：Customized
  • Condition：New
  • Control Type：CNC
  • Automatic Grade：Automatic
  • Drive：Hydraulic

Base Info

  • Model NO.：metal fence
  • Automation：Automatic
  • Tolerance：0.5mm
  • Type：Roll Forming Machine
  • Processing：Roll Forming Machine
  • Method：Roll Forming Machine
  • Product：Steel
  • Brick Raw Material：Steel
  • Transport Package：Standard Export Package, Water-Proof Package
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Cangzhou City, Hebei Province, China
  • HS Code：84552210
  • Production Capacity：10sets,Per Month

Description

Molding host

Model

Shibo-metal stud roll forming machine

Forming size

4500mm*1500mm*1300mm

weight

2.5 T

Host big frame structure

Frame welded

Roll station

14row

Axial material

45# steel

Out diameter of shaft

Φ50mm

Roller materials

CR12

Drive

By chain and gear

Sprocket chain

1 inch

Main power

7.5 kw

Working speed

45 m/min

Material thickness

0.3-1.0mm



Made board

25mm


Light Steel Keel Metal Furring Keel Channel House Structure Roll Forming Machine



Steel Beam Machine/Gutter Machine/KeelMachine/Steel Profile Machine/Metal Cold Forming

This type is made order by Russian customer. And this ceiling type is most popular used in Russia.

Our machines are certificated by CE SGS BV TUV, donot need doubt with our mahcines quality.

We ever sold machines all over the world, such as: US, UK, Canada, Brazil, Russia, India, Negria, Italy, Zimbabwe, Sri Lanka, Azerbaijan...

Packing:
1. One 20 feet container for loading one set machine with mechanical decoiler.
2. Main machine body and decoiler is load naked (tighten to container with steel wire rope).
3. Spare parts and operating tools are loading in tooling box.

Delivery: about 30 days.

Where is your factory located ? How can I visit you ?
Dixin Roll forming machinery is located at Industrial Zone of Botou , Hebei Province of China. Welcome to visit us by:

1.Fly to BEIJING or TIANJIN Airport, then take high speed train from BEIJING NAN to CANGZHOU XI, about 1 hour, I will pick up you there.
2.Fly to SHANGHAI Airport, then take high speed train from SHANGHAI HONGQIAO to CANGZHOUXI, about 4.5 hour,I will pick up you there.
