• Model NO.：LMD-120
• Voltage：380V
• Power Volatge：380V,220V or Other
• Rating Power：1.5kw
• Rating Air Pressure：16MPa
• Air Consumption Pressure：0.5~0.8MPa
• Genenral Pressure：48kn
• Air Consumption：3L,Min
• Capability of Oil Box：20L
• Profile Height：90mm
• Overall Dimension：1100X1200X1200mm
• Machine Color：Customer Choose
• Transport Package：Wooden Box
• Specification：1100x1200x1200mm
• Origin：Shandong, China
• HS Code：84659200
• Production Capacity：40000PCS,Per Year

Basic Info.

Model NO. LMD-120 Voltage 380V Power Volatge 380V/220V or Other Rating Power 1.5kw Rating Air Pressure 16MPa Air Consumption Pressure 0.5~0.8MPa Genenral Pressure 48kn Air Consumption 3L/Min Capability of Oil Box 20L Profile Height 90mm Overall Dimension 1100X1200X1200mm Machine Color Customer Choose Transport Package Wooden Box Specification 1100x1200x1200mm Origin Shandong, China HS Code 84659200 Production Capacity 40000PCS/Per Year

Product Description

High Quality Window Machine Corner Combining Machine for Aluminumn Window door Corner Crimping Machine
Main Feature:
1).uitable to connection of 90 angle structure of aluminum door and window.
2).The frame is specially jointed by steel with high quality and then does special process
3). Adopt new mechanical linkage device,realized complete synchronous corner combining.
4). Synchro feeding structure make the adjustment very easy. Synchronous feeding of the level(left and right side) pushing knives by link with one hydraulic cylinder driving, which avoid the corner deform and enhance the corner connection efficiently.
5). Screw thread regulates the distance between up and down crimping blade ensures regulates easily.
6). It is collocate single cutter of many points crimping cutter ensure reliably crimping heat insulation aluminum windows and doors
7). Hydraulic system driving, ensure a stable working
8).  Distance of tool knife adjustable, as the screw thread connection, easy working for tools.
Main Technical Parameter:

Power supply	380V 50Hz or other
Input power	1.5kw
Air pressure	0.6-0.8M pa
Rated pressure	15Mpa
Capability of oil box	20L
Profile width	90mm
Corner combining casing movement journey	85mm
The adjustable range of the main location block	54mm
Over all dimension: (L × W ×H)	1100*1200*1200mm
Weight:	400Kg

Standard accessory

Mobile work piece supports	2set
Standard Crimping Cutter	1set
Complete tooling	1set
Certificate	1pc
Operation Manual	1pc

Optional tools

Special crimping cutter	Based on the profile section.
Automatic up-down function	can choose add
