Qgm Small-Scale Concrete/Cement Paver Block Making Machine
Quangong Machinery Co., Ltd.- Warranty：1 Year
- Certification：ISO&CE
- Automatic Grade：Automatic
- Type：Vibration Molding
- Condition：New
- Method：Hydraulic Pressure
Base Info
- Model NO.：QT 10
- Brick Size：400*100*200 mm, 200*100*60 mm, 400*150*200 mm
- Cycle Time：15-20 Seconds
- Key Selling Points：Easy to Operate
- After Warranty Service：Video Technical Support, Online Support
- Pallet Size：1250mmx850mm
- Voltage：380V
- After-Sales Service Provided：Field Installation, Commissioning and Training
- Total Weight：15t
- Applicable Industries：Building Material Shops, Construction Works
- Core Components：PLC
- Production Capacity (Pieces/8 Hours)：11500-15000PCS Per Shift
- Motors Power：53kw
- Transport Package：Standard Seaworthy Packing
- Specification：9600x4450x3000MM
- Trademark：QGM
- Origin：Fujian, China
- Production Capacity：100 Set,Sets Per Month
Description
Production per Shift (8 Working Hours):
Hollow Block (400x200x200mm): 14400-19200 pcs
Solid Block (240x115x53mm): 77760-103680 pcs
Interlock (225x112.5x60mm): 31104-38880 pcs
Holland Brick (200x100x60-80mm): 4032050400 pcs
Vibrating Frequency:
2940 rolls/minute or 50 HZ
Motors Power:
53 KW
Machine Dimensions:
7568x2060x2968mm (excluding electrical control box)
Pallet Size:
1250x850mm
Gross Weight:
about 15T
Raw Materials:
crushed stone, sand, cement, dust and coal fly ash, cinder, slag, gangue, gravel, perlite, and other industrial wastes
Applied Products:
concrete blocks, solid/hollow/cellular masonry products, paving stones with or without face mix, garden and landscaping products, slabs, edgers, kerbstones, grass blocks, slope blocks, interlocking blocks, etc.
Applied Fields:
widely used in buildings, road pavings, squares, gardens, landscaping, city constructions
QGM QT10 Block Making Machine with Five Advantages: 1.Use Frequency Conversion Control Technology
a) Under the frequency conversion control, this automatic block making machine utilizes the precise guide bearings to ensure the precise and parallel movement between the tamper head and mould.
b) With the frequency-controlled vibration, the motors are controlled properly for its instantaneous start and stop.
c) This product is able to generally save20- 30% power.
D)adopt a braking unit with a resistor for turning off the machine in order to stop the excess energy consumption, which can solve the problem of inertia when machinery stops working
E)adjusting the speed of the electric motor is workable, and it can Improve product quality(Improve the density)2. This automatic block making machine utilizes double proportional and directional valves with high activity to regulate the oil flow and pressure automatically, protecting the hydraulic cylinder from being damaged, which plays a buffer role in the process of production. And this kind of design of machinery can ensure stable production and prolong the lifetime of the machine.3. Adopt 360° Multi-shaft rotating and compulsory feeding to offer high speed rotating and compulsory feeding and uniform mixing for the materials. With the even feeding performance, this product is suited for diverse raw materials and moulds.4. Electrical system machinery equipped is Germany Siemens PLC control system, touch screen and electrical components. The control system is of easy operation and low failure ratio. The machinery is equipped with a data input and output devices and data formula function. it can be used for permanent preservation. And the machinery has the function of timely equipment fault diagnosis and alarm system, fault alarm is self-explanatory, which can be convenient in machine maintenance and troubleshooting. The Control System for safety has logic control with a self-locking function in order to protect the machinery from damage because of operational error. It can also solve the problem via telephone, which can realize the remote control and program upgrade.5. The main machine is an adopted special material, which has the advantages of vibration resistance and no deformation.Mould material carburizing treatment, which possesses the advantages of wear and abrasion resistance, extends the service life by more than 50% compared to traditional mould.
