Building Material Making Machinery

Aluminum Windows and Doors Profiles CNC Processing Machine

JINAN YUEFENG MACHINERY CO., LTD.
  • Condition:New
  • Certification:CE
  • Automatic Grade:Semi-Automatic
  • CNC or Not:CNC
  • Voltage:380V
  • Model:Lzxa-CNC-1400

Base Info

  • Model NO.:LZXA-CNC-1400
  • Input Voltage:380V 50Hz
  • Input Power:8kw
  • Spindle Power:4.5kw
  • Spindle Speed:0~18000r,Min
  • X-Axes Travel:1400mm
  • X-Speed:0~60m,Min
  • Y-Axes Travel:450mm
  • Y-Speed:0~30m,Min
  • Z-Axes Travel:360mm
  • Transport Package:Wooden Case
  • Specification:11000*1800*2300mm
  • Trademark:Yuefeng
  • Origin:Jinan Shandong, China
  • HS Code:8477800000
  • Production Capacity:10 Sets,Month

Description

Basic Info.

Model NO. LZXA-CNC-1400 Input Voltage 380V 50Hz Input Power 8kw Spindle Power 4.5kw Spindle Speed 0~18000r/Min X-Axes Travel 1400mm X-Speed 0~60m/Min Y-Axes Travel 450mm Y-Speed 0~30m/Min Z-Axes Travel 360mm Transport Package Wooden Case Specification 11000*1800*2300mm Trademark Yuefeng Origin Jinan Shandong, China HS Code 8477800000 Production Capacity 10 Sets/Month

Product Description

Aluminum Windows and Doors Profiles CNC Processing Machine
LZXA-CNC-1400
Aluminum Windows and Doors Profiles CNC Processing Machine
Aluminum Windows and Doors Profiles CNC Processing Machine
> This machine is mainly used for processing all kinds of mounting holes, lock holes, launders and other slots on various profiles. It can work on aluminum alloy, non-ferrous metal, orbit construct and pvc profiles, etc. Once clamping, multiple hole drilling and milling be finished, high efficiency.

> Linear guide kinematic pair, ball screw, gear rack and imported servo motor be adopted in this machine, results high stable and accuracy for locating and processing.

> The main shaft adopts HSD originally imported from Italy, results stable rotation, small noise and high efficiency.

> Order your own mill tools, the mill tools can be selected automatically during working.


Technical Parameter:
ModelLZXA-CNC-1400
Input voltage380V 50Hz
Input power8Kw
Spindle power4.5Kw
Spindle speed0~18000r/min
X-axes travel1400mm
X-speed0~60m/min
Y-axes travel450mm
Y-speed0~30m/min
Z-axes travel360mm
Z-speed0~30m/min
Process range1400×12120mm
Overall dimension2300×1500×2000mm
