C Z U Metal Stud and Track Cold Roll Forming Machine

Cangzhou Nexus Machinery Co., Ltd.
  • Warranty：1 Year
  • Certification：CE, RoHS, GS, ISO9001, SGS
  • Customized：Customized
  • Condition：New
  • Control Type：Electric
  • Automatic Grade：Automatic

Base Info

  • Model NO.：NX100
  • Product Name：C Purlin Metal Stud and Track Machine
  • Coil Material Thickness：0.3-0.8mm
  • Processing Material：Galvanized Steel
  • Roller Material：Cr12MOV
  • Diameter of Shaft：56mm
  • Forming Speed：15-25m,Min
  • Package：One Full Set of 20 Feet Container
  • Transport Package：Control Box and Easy Damaged Parts: Protective PA
  • Specification：60-27-28
  • Trademark：Nexus Machinery
  • Origin：Cangzhou
  • HS Code：8455221000
  • Production Capacity：10 Sets,Month

Description

Feeding material

 PPGI / GI plate

Frame typesteel board weldedWidth of the plate94mmThickness of the plate0.3 - 0.75mmDimensions

5500mm*1200mm*1400mm

Diameter of the shaftΦ45mmRoller station12rowsProductivity15-20m/minMotor power to drive the machine5.5 + 4 kwVoltage380V 50Hz 3phase or as per requirementWeight2900kgsMaterial of the cutting headGr12 , heat treatment HRC58-60Machine framesteel board welding frameSide board thickness25mmC Z U Metal Stud and Track Cold Roll Forming Machine

C Z U Metal Stud and Track Cold Roll Forming Machine

C Z U Metal Stud and Track Cold Roll Forming Machine

C Z U Metal Stud and Track Cold Roll Forming Machine
C Z U Metal Stud and Track Cold Roll Forming Machine
C Z U Metal Stud and Track Cold Roll Forming Machine

ABOUT US:

C Z U Metal Stud and Track Cold Roll Forming Machine
More Products for Your Choose:
C Z U Metal Stud and Track Cold Roll Forming Machine

FAQ:
1. How long the machine could be made?- Normally speaking, light gauge steel frame machine could
be made within 45 working days. If you need machines in a hurry, we can make it for you
less than a month.
2. How to visit your company?
-a.Fly to Beijing airport:   By high speed train From Beijing Nan to Cangzhou Xi (1 hour),
then we can pick up you.
b.Fly to Shanghai Airport: By high speed train From Shanghai Hongqiao to Cangzhou Xi(4.5
hours), then we can
pick up you.
3. Do you have after sales support?
-Yes, we are happy to give advice and we also have skilled technicians available across the
world.We need your machines running in order to keep your business running.
