Rotary Kiln for Mini Cement Plant Line
Henan Zhengzhou Mining Machinery Co., Ltd.- Application：Construction, Chemical Industry, Mineral Operation, Cement Production
- Certification：CE, ISO, ISO9001: 2000, ISO 9001:2000, ISO 9001:2008
- Customized：Customized
- Automatic Grade：Automatic
- Condition：New
- After Sale Service：We Offer
Base Info
- Model NO.：1.4× 33m
- Design：We Offer
- Installation：Uner Our Engineers′ Guide
- Experience：Over 50 Years
- Certificate：ISO9001, ISO14000, Ce
- Spare Parts：We Offer
- Capacity：Can Be Customized
- Warranty Period：12 Months
- Technical Parameters：See Technical Table
- Transport Package：Standard Export Packing
- Specification：ISO9001, ISO14000, CE
- Trademark：ZK
- Origin：Zhengzhou, China
- HS Code：8417
- Production Capacity：Reference to The Form
Description
DimensionCapacity(t/h) Rotation Speed(r/min) Motor Power(kw) Weight(T) Remarks Diameter(mm) Length(mm) Slope (%) Φ1.4×33 1.4 33 3 0.9-1.3 0.39-3.96 18.5 47.5 -- Φ1.6×36 1.6 36 4 1.2-1.9 0.26-2.63 22 52 -- Φ1.8×45 1.8 45 4 1.9-2.4 0.16-1.62 30 78.2 -- Φ1.9×39 1.9 39 4 1.65-3 0.29-2.93 30 77.59 -- Φ2.0×40 2 40 3 2.5-4 0.23-2.26 37 119.1 -- Φ2.5×45 2.2 45 3.5 3.4-5.4 0.21-2.44 45 128.3 -- Φ2.5×40 2.5 40 3.5 9.0-10.5 0.44-2.44 55 149.61 -- Φ2.5×50 2.5 50 3 6.25-7.4 0.62-1.86 55 187.37 -- Φ2.5×54 2.5 54 3.5 6.9-8.5 0.48-1.45 55 196.29 -- Φ2.7×42 2.7 42 3.5 10.0-11.0 0.10-1.52 55 198.5 -- Φ2.8×44 2.8 44 3.5 12.5-13.5 0.437-2.18 55 201.58 Suspension Preheater Kiln Φ3.0×45 3 45 3.5 12.8-14.5 0.5-2.47 75 210.94 -- Φ3.0×48 3 48 3.5 25.6-29.3 0.6-3.48 100 237 Precalcining Kiln Φ3.0×60 3 60 3.5 12.3-14.1 0.3-2 100 310 -- Φ3.2×50 3.2 50 4 40.5-42 0.6-3 125 278 Precalcining Kiln
