• Model NO.：Floor Deck Roll Forming Machine
• Customized：Customized
• Usage：Floor
• Transmission Method：Hydraulic Pressure
• Name：Building Floor Bearing Deck Steel Floor Tile Press
• Roller：24rollers
• Dimensions：10*1.45*1.51m
• Power：7.5+5.5kw
• Thickness of The Plate：0.8-1.2mm
• Productivity：8-10m,Min
• Material of The Cutting Blade：Cr12
• Diameter of The Roller：70mm
• Weight：About 6.8t
• Voltage：380V 50Hz 3phases
• Transport Package：Water-Proof Packaging, Covered with Plastic Film
• Specification：CE ISO
• Trademark：DIXIN
• Origin：Botou Hebei China
• HS Code：845522
• Production Capacity：20 Set Per Year

1.Processing material

aluzinc/galvanized steel/colored steel coil

2.Material thickness

Max2mm

3.Feeding width:

1200mm

4.Effective width

1000mm As design

5.Main motor power

30kw

6.Pump station power

7.5kw

7. Shaft diameter

100mm solid shaft ,Surface of roller coated with chrome 0.05mm thickness

8.Forming steps

20 steps

9.Main frame

400H Steel frame

10. Side plate thickness

20mm

11.Roller material

45 # forged material, high frequency quenching, hard chromium plating

12.Control systerm

Panasonic PLC control with touch screen,Mitsubishi frequency converter ,Encoder(Omron)

13.Cutting blade material

Cr12

14.Working speed

About 15-20m/min

15. Transmission way

1.5 inch double chain

16. Machine size (mm)

About 11.8m*1.6m*1.6m

17.Power supply

380v,3phase,50hz or accodring to customer request

18 Electric Pre- cutter

Add a motor with chain drive

3.Main Components:

No

Name

Qty

1

Main Rolling Machine

1set

2

10ton electric decoiler

4 set

3

Hydraulic Cutting

1set

4

PLC control system

1set

5

Electric motor 7.5kw*2

2set

6

Hydraulic Pump Station

1set

7

Output table

2sets

8

Spare parts

1 box

Working flow:
manual uncoiler-roll forming machine-computer control system-hydraulic system-forming part-cutting part-discharge table
No
Technical Specification
1
Manual Uncoiler
Usage:It is used to support the steel coil and uncoil it in a turnable way. The steel coil is uncoiled by hand. Loading capacity:1.2T,Inner diameter: 500-508mm
2
Feeding Table
Put the raw material(steel plate) through the beach to manufacture and process, it can guarantee that the products are neat, parallel and everything is uniformity. Please refer to the equipment regulation to know the function of locate angle iron.
3
Main Roll Forming Machine
Material of rollers:45# steel,roller surfaces polishing, hard plating , The polished surface and the heat treatment towards the molds also can keep the molding plate surface smooth and not easy to be marked when it is being stamped
4
Hydraulic System
Computer Control Cabinet
Power:5.5kw,Hydraulic oil: 40#
hydraulic oil into the hydraulic oil tank ,the pump drive the cutter machine to begin the cutting job.
The target piece`s length is adjustable and digit of it can be adjusted. Computed mode has two modes: automatic and manual one. The system is easy to operate and use
PLC:EURA
5
Shearing Mechanism
It adopts the hydraulic drive and automatic location to decide the dimension and cut the target products.
Material of blades: Cr12,quenching treatment
6
Output Table

It adopts welded steel and supported roller to transmit the products,which is used to collect the finished products.
