• Model NO.：950-1250
• Main Frame：300h,500h
• Effective：Easy Operation
• Motor Power：4kw
• Forming Station：13 Stations
• Medium Plate Thickness：14mm
• Main Power：7.5kw
• Diameter of Roller：75mm
• PLC：Delta Brand
• Type：Roll Forming Machine
• Method：Cold Roll Forming Machine
• Transport Package：One 20 Feet Container for Loading Machine
• Specification：CE, SGS
• Trademark：DIXIN
• Origin：Cangzhou City, Hebei Province, China
• HS Code：84552210
• Production Capacity：20sets,Per Month


                                                                              Technical parameterItemSpecification
Raw MaterialPre-painted steel coil & galvanized coils0.3-0.8235-550Roller material45# steel , coated with ChromeShaft for rollers shaft with 75mm,processed with cylindrical grinderForming speed(m/min)About 8-12Output speed(m/min)About 12 for 6m length sheetSpeed adjusting modeMitsubishi frequency transformerRoller drive                                               Decelerating motor + Chain driveCutting modeautomatic hydraulic cut to lengthCutter material Cr12 mould steelLength measurementNemicon EncoderControl modeMitsubishi PLCOperating modeButton + Mitsubishi Touch screenMain motor power(kw)4KWTotal power(kw)8 KW
Process flow

Decoiler -- Feeding & Guiding -- Roll forming---Hydraulic Cutting - product to run out table
Components of machine
 Decoiler (manual decoiler and hydraulic decoiler for option)1set  Feeding & guiding device1setMain roll forming machine1setHydraulic cutting system1setControlling system1setRun out table (auto. Stacker for option)1set

Packaging &Shipping

1.Packaging Details:Nude,with waterproof cloth and stow-wood. Imported computer control system packed with waterproof cloth and card board.
2.Port:TIANJIN XINGANG PortLead .
3.Time: Shipped in 35 days after payment.
Usually the welding pipe cold roll forming machine can be packed into one 20' feet container or 40' feet container. We have good relationship with the shipping agent. Either you can find the shipping line at your side or we can help you.



Our service

1. Installation and training:
a.If buyers visit our factory and check the machine, we will teach you how to install and use the machine, and also
train your workers/technician face to face.
b.Without visiting, we will send you user manual and video to teach you to install and operate.
c.If buyer needs our technician to go to your local factory, please arrange board and lodging and other necessary
things.
2. After Service
a.One year guarantee for whole machine.
b.24 hours technical support by email or calling

More type maybe you need


FQA

Q:Are you a manufacturer?
A:Yes absolutely. Welcome a lot for your visiting to us.
Q:What's the delivery time?
A:Normaly will take 60days, for small lines will take 30 days.
Q:Do you have after-sale support?
A:Yes, we're always here for giving you advice and support for technical details since we have senior technician.
Q:Is there quality control when manufacturing the lines?
A:Yes, we have a group of team who will be responsible for quality control from laying off the raw material, processing the rollers and the other parts, make treatment on the roller surface and shaft, assembling, testing and packaging.
Q:What's your strength comparing to the other supplier?
A:We'll supplying you the best quality and service. We'll give you good advise beyond your requirements. The lines are easily for installation and with low mantenance requirements.
Q:Can we be your agency abroad?
A:Surely if you have business for roll forming lines and we will welcome a lot for cooperating together.

if u have any interest,please contact me any time
