Galvanized Drywall Used U Profile Light Gauge Steel Roll Forming Machine

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Warranty：12 Months
  • Tile Type：Colored Steel
  • Certification：CE, ISO, CCC, ISO9001
  • Condition：New
  • Customized：Customized
  • Usage：Roof, Wall, Floor

Base Info

  • Model NO.：DX U
  • Transmission Method：Machinery
  • Type：Rolling Machine
  • Power Source：Hydraulic Pressure
  • Feature：High Efficiency
  • Advantage：Use Widely
  • Forging Forming Method：Mold Forging
  • Name：U Light Keel Roll Forming Machine
  • Roller Station：10 Stations
  • Shaft Material：45# Steel
  • Outer Diameter：40mm
  • Transport Package：Water-Proof Packaging, Covered with Plastic Film
  • Specification：DX U
  • Trademark：DIXIN
  • Origin：Botou Hebei China
  • HS Code：845522
  • Production Capacity：20 Set Per Month

Description

Basic Info.

Model NO. DX U Transmission Method Machinery Type Rolling Machine Power Source Hydraulic Pressure Feature High Efficiency Advantage Use Widely Forging Forming Method Mold Forging Name U Light Keel Roll Forming Machine Roller Station 10 Stations Shaft Material 45# Steel Outer Diameter 40mm Transport Package Water-Proof Packaging, Covered with Plastic Film Specification DX U Trademark DIXIN Origin Botou Hebei China HS Code 845522 Production Capacity 20 Set Per Month

Product Description

Galvanized Drywall Used Omega Profile Light Gauge Steel
1.1 Coil material thickness: 0.4-0.6mm
1.2 Material: GI GL PPGI PPGL
Process flow
De-coiler--Feeding--Forming--Cutting--Product Table
Manual De-coiler
1). Material coil inner diameter: 450mm-550mm
2). Max coil Width: 400mm

3). Carrying capacity: 1.5T
Forming System
1). Roller station: 10 stations
2). Shaft material: 45# steel
Outer diameter: 40mm
Roller material: GCr12MoVo
3). Transport: Gear Driving
4). Forming Speed: 20m/min
5). Motor: 4kw
6). Size: 4.2mx1.2mx1.5m

7). Voltage: 380v, 50Hz, 3phase
Hydraulic
Cutting System
5.1 Hydraulic Station: 1set
5.2 With hydraulic station, motor 3 KW
5.3 HydGalvanized Drywall Used U Profile Light Gauge Steel Roll Forming Machineraulic cutting

5.4 Blade material: Cr12 steel with quenched treated 60-62° C

5.5 Cutting system: Advanced hydraulic drive, automatic cutting after forming,
6. Control System
6.1 Screen: Touch screen
6.2 PLC: Delta
6.3 Automatic length measurement
6.4 Automatic quantity measurement
6.5 Computer is used to control length and quantity. Machine will automatically cut to length and stop when required quantity is achieved
Galvanized Drywall Used U Profile Light Gauge Steel Roll Forming Machine

Service and Warranty
1. Warranty time: One year, and we will provide the technical support for the whole life.

2. What's more, one year for free, after the warranty period. We will help you repair the machine, you only responsible for the labour and parts, when the machine have some problem.



If u have any interest,please contact me any time
