Building Material Making Machinery

50t, 80t, 100t, 150t, 200t Cement Powder Storage Silo Tank

Zhengzhou Focus Machinery Co., Ltd.
  • Certification:CE, ISO9001: 2000
  • Condition:New
  • Type:Cement Production Machinery
  • Machining Process:Vacuum
  • Cement Storage Volume:50t
  • Cement Silo Type:Complete Type

Base Info

  • Model NO.:50 ton
  • Average Thickness:6-8mm
  • Cement Silo Diameter:2.5m,3m,3.5,3.8,4.1m
  • Cement Silo Height:8.7,11.4,11.8,13,14.5m
  • Total Height:16,18,20.3,22,22.8m
  • Matched Mixer:Js500,750,1000,1500,2000,3000,Sicoma Mixers;
  • Transport Package:Standard Packing for International Transport
  • Specification:ISO CE certified
  • Trademark:FOCUS
  • Origin:Henan Zhengzhou
  • HS Code:8479899200
  • Production Capacity:100 Sets Per Month

Description

Basic Info.

Model NO. 50 ton Average Thickness 6-8mm Cement Silo Diameter 2.5m/3m/3.5/3.8/4.1m Cement Silo Height 8.7/11.4/11.8/13/14.5m Total Height 16/18/20.3/22/22.8m Matched Mixer Js500/750/1000/1500/2000/3000/Sicoma Mixers; Transport Package Standard Packing for International Transport Specification ISO CE certified Trademark FOCUS Origin Henan Zhengzhou HS Code 8479899200 Production Capacity 100 Sets Per Month

Product Description

Q235 steel cement silo for cement storage:
Sizes of FOCUS Cement silo:
Integral type cement silo: 50t
Bolted type cement silo: 50t, 80t, 100t, 150t, 200t, etc.
Description of FOCUS Q235 steel cement silo for cement storage?
FOCUS Q235 steel cement silo is a kind of closed huge column-shape tank storing bulk materials. The Q235 steel cement silo is suitable for storing bulk materials such as grains, cement, powder and fly-ash. Material level system is installed in the silo, which can show the position and quantity of the materials. The arch-breaking equipment can clear up hard materials from long time sediment. The materials can be sent to all the positions with the combination of cement silo and screw conveyor pump. Easy installation with its characteristics of safety and reliability make it an ideal cement bin for the concrete mixing plant. 30T, 50T, 80, 100T, 150T, 200T, 300T, 500T detachable and whole piece cement silos can be chosen according to clients' requirements.

50t, 80t, 100t, 150t, 200t Cement Powder Storage Silo Tank50t, 80t, 100t, 150t, 200t Cement Powder Storage Silo Tank50t, 80t, 100t, 150t, 200t Cement Powder Storage Silo Tank50t, 80t, 100t, 150t, 200t Cement Powder Storage Silo Tank50t, 80t, 100t, 150t, 200t Cement Powder Storage Silo Tank

Model

Silo diameter

Silo height

Total height

Matched mixer

Matched screw

50T

2.5m

8.7m

16m

JS500/JS750/JS1000

LSY219/LSY273

100T

3m

11.4m

18m

JS1000/JS1500/JS2000

LSY219/LSY273

150T

3.5m

11.8m

20.3m

JS1000/JS1500/JS2000/JS3000

LSY273/LSY325

200T

3.8m

13m

22m

JS2000/3000/MAO3000/2000/MAO4500/3000

LSY273/LSY325

300T

4.1m

14.5m

22.8m

JSseries/MAO4500/3000/MAO6000/4000/MAO7500/5000

LSY325
