Kexinda Sandwich Panel Making Machine
HEBEI XINNUO ROLL FORMING MACHINE CO., LTD.- Tile Type：Colored Steel
- Certification：CE, ISO
- Condition：New
- Customized：Customized
- Usage：Roof
- Transmission Method：Machinery
Base Info
- Model NO.：sandwich panel making machine
- Product Name：Sandwich Panel Making Machine
- Transport Package：Nude with Simple Plastic
- Specification：45M
- Trademark：KXD
- Origin：China
- HS Code：8455221000
- Production Capacity：10sets,Month
Description
Basic Info.
Model NO. sandwich panel making machine Product Name Sandwich Panel Making Machine Transport Package Nude with Simple Plastic Specification 45M Trademark KXD Origin China HS Code 8455221000 Production Capacity 10sets/MonthProduct Description
SANDWICH PANEL ROLL FORMING MACHINETechnical specification
1. Technique parameters of the processing line
(1) Coil material: EPS, rock wool, glass silk floss and so on
(2) Thickness of the plate: 0.3-0.8mm
(3) Core thickness: 20-300mm
(4) Production capacity (according to your glue):
4-4.5m/min (the fastest), 2-2.5m/min(the slowest)
(5) Total power: about 30KW
(6) Weight: 25ton
(7) PLC control systerm, easy to operate, high precision and work stably.
(8) Dimensions of whole production line:
About Length35000mm × Width2500mm × Height2600mm
2. Processing technique and deployment
Processes: Composite Decoiler-Roll Forming-laminating system (ribbon, gelatinizing, heating up, compounding, crimping, notching, edge trimmer)-cutting system-Runout Table
