Building Material Making Machinery

Factory Supply Double Head Precision Cutting Saw for Aluminum Profile

Shandong Truetec Machinery Co., Ltd.
  • Condition:New
  • Certification:CE
  • Automatic Grade:Automatic
  • CNC or Not:not CNC
  • Voltage:380V
  • Input Power:4.4kw

Base Info

  • Model NO.:CLJZ2X-500x4200
  • Rotary Speed:2800r,Min
  • Air Consumption:60L,Min
  • Cutting Length:400-4200mm
  • Cutting Width:135mm
  • Cutting Height:200mm
  • Cutting Angle:45 and 90 Degree
  • Machine Dimension:5500*1750*1950mm
  • Weight:1800kg
  • Transport Package:Wooden
  • Specification:Saw blade diameter 500mm
  • Trademark:Truepro
  • Origin:China
  • HS Code:846150
  • Production Capacity:500sets,Year

Description

Basic Info.

Model NO. CLJZ2X-500x4200 Rotary Speed 2800r/Min Air Consumption 60L/Min Cutting Length 400-4200mm Cutting Width 135mm Cutting Height 200mm Cutting Angle 45 and 90 Degree Machine Dimension 5500*1750*1950mm Weight 1800kg Transport Package Wooden Specification Saw blade diameter 500mm Trademark Truepro Origin China HS Code 846150 Production Capacity 500sets/Year

Product Description

Factory Supply Double Head Precision Cutting Saw for Aluminum Profile
Factory Supply Double Head Precision Cutting Saw for Aluminum Profile

Ma
chine feature:

1.It has features of easy operation, reliable performance, advanced technique and convenient maintenance, etc.
2. The profile cutting size adopts and digital display technique to ensure high efficiency and accuracy.
3. Imported carbide saw blade gives accurate processing and high efficiency.
4. Two cutting head can work together or single. When together work, one time can cut off the required length and angle
5. With digital display to show cutting length, easy operate.
Parameter:
Power supply3N~50Hz 380/220V or As Customer Specification
Cutting motor power4.4KW
Cutting motor rotary speed2800r/min
Operation air pressure0.5~0.8MPa
Air consumption60L/min
Blade specificationø500×ø30×4.4×Z120
Cutting speedstepless speed regulation0~3m/min
Max. cutting length4200 mm
Min. cutting length400 mm
Cutting widthmax 135mm
Cutting height90 :  max  300mm      45:  max  200mm
Cutting angle90°,45°
Repeat locating length tolerance±0.2mm
Cutting profile surface plane≤0.10mm
Cutting angle tolerance±5′
Cutting profile surface roughnessRa12.5µm
Contour dimension5700 mm×1750mm×1950mm
Weight1800KGS
Machine details:
Factory Supply Double Head Precision Cutting Saw for Aluminum Profile


Factory Supply Double Head Precision Cutting Saw for Aluminum Profile

Factory Supply Double Head Precision Cutting Saw for Aluminum Profile
Factory Supply Double Head Precision Cutting Saw for Aluminum Profile
Factory Supply Double Head Precision Cutting Saw for Aluminum Profile

Factory Supply Double Head Precision Cutting Saw for Aluminum Profile

1. When can we arrange shippment?
We usually arrange shippment within 15 days after getting deopsit,
but customized machines should be more than 25 days.

2.What you can do if my machines have problems?
1) We can send you free components to you if your machines are in guarantee time.
2) We can dispatch our engineers to repair your machines

3.Do you provide equipment operation training?
A: Yes. We can send professional engineers to the working site for equipment installation, adjustment, and operation training.
All of our engineers have passport.


4. If I make Aluminum window and door, how many basic machines do i need?
1).double head cutting saw
2).Lock hole copy milling machine
3).End milling machine
4).Automatic Corner connector automatic cutting saw
5).Single head Corner combining machine
