Colored Steel Corrugated Sheet Cold Forming Line/Profile Roof Sheet Machine /Iron Roofing Tiles Making Machine

Cangzhou Dixin Roll Forming Machine Co., Ltd.
  • Certification：CE, ISO, Corrugated Iron Roofing Machine
  • Condition：New

Base Info

  • Model NO.：corrugated iron roofing machine
  • Customized：Customized
  • Usage：Roof, Wall, Floor, Corrugated Iron Roofing Machine
  • Transmission Method：Hydraulic Pressure
  • Product Name：Corrugated Iron Roofing Machine
  • Control System：PLC
  • Rolller：High Grade 45# Steel
  • Froming Steps：13
  • Hydraulic Pump Station：4kw
  • Motor Power：5.5kw
  • Chain：1inch
  • Cutter：Cr12
  • Middle Plate：14mm
  • Shaft：75mm
  • Transport Package：Nude, Covered with Plastic Film
  • Specification：CE, SGS
  • Trademark：DIXIN
  • Origin：Botou, Hebei, China
  • HS Code：84552210
  • Production Capacity：30 Sets,Month

Description

Main parameter for1Suitable to processGalvanized/Aluminum/Color steel sheet2Width of plate1250mm3Thickness of plate0.3-0.8mm4RollersHigh grade 45# steel, with hard chrome plating5Forming steps166Sprocket chain1.5 inch7Pump station power4kw8Shaft75mm, high grade 45# steel, heat treatment9Hydraulic oil pumpCB-E31010WeightAbout 5.0 tons11Productivity8-12m/min12Cutting headCr12 mould steel with quenched treatment13Control systemTAIDA brand PLC control14Voltage380V 3Phase 60Hz15Motor power4kw16DimensionAbout 6.8m*1.5m*1.5m17Hydraulic pressure10-12mpa18Index error of length±1mm19The temperature range of working line-35-50°Above all the parameters can be changed exactly according to customer's requirements.

5. Want a free quotation for make budget?
Just send inquiry to me now!
6. We are your reliable partner!
We always do the best to make our machine perfect in every detail part.
Any pics or videos about machine, we can provide you.
7. Payment terms
30% T/T as the deposit when contract signed, 70% balanced before shipping.
8.Company information
Colored Steel Corrugated Sheet Cold Forming Line/Profile Roof Sheet Machine /Iron Roofing Tiles Making Machine


 If you have any question,please contact me!
